System And Components
3G-9243 BOWL GP-SCRAPERS/N 86Z222-240
Group No: 3G-9243
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3G9951 | 1 BOWL AS | 1 | |
| 5H6106 | LUG (34MM) | 1 | |
| 2D1641 | LUG (10.3MM) | 1 | |
| 2G7492 | LUG (89MM) | 1 | |
| 4D7529 | BOSS (3/8-16-THD)(8.2MM) | 5 | |
| 4J3818 | BLOCK-TAPPED (50.8MM) | 1 | |
| 5B5456 | LUG (38MM) | 2 | |
| 6M4263 | BOSS (11MM) | 5 | |
| 8D7729 | BOSS (3/8-16X0.81-IN)(8.2MM) | 2 | |
| 8J7574 | LUG (50MM) | 1 | |
| 9D1205 | BLOCK (57MM) | 1 | |
| 8W1247 | 2 RAIL AS | 2 | |
| 8W5916 | 3 TRACK AS | 1 | |
| 8W5917 | TRACK AS | 1 | |
| 3D2365 | 4 CLIP | 10 | |
| 1U4100 | 5 HOOK-RETRIEVAL | 2 | |
| 1U4217 | 6 PLATE | 1 | |
| 1F0748 | 7 NUT-WELD (1/2-13-THD)(20.64MM) | 7 | |
| 8J7236 | 8 NUT-WELD (3/4-10-THD)(28.58MM) | 4 | |
| 8W4993 | 9 PLATE | 1 | |
| 8W4992 | 10 PLATE | 1 | |
| 7F6252 | 11 FITTING-PLUG | 1 | |
| 6B4112 | 12 FITTING-PLUG | 1 | |
| 6G3154 | 13 PLATE | 1 | |
| 2J7792 | 14 SPACER | 1 | |
| 8F9836 | 15 BOSS (3/8-16-THD)(19MM) | 22 | |
| 6J5953 | 16 PIN | 2 | |
| 4J5193 | 17 PIN | 2 | |
| 0L1178 | 18 BOLT (3/4-10X2-IN) | 2 | |
| 4T1473 | 19 CLAMP (LARGE HOLE) | 1 | |
| 4T1474 | CLAMP (SMALL HOLE) | 1 | |
| 1D4569 | 20 BOLT (1/2-13X4.25-IN) | 2 | |
| 5P8245 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 22 | |
| 7S9372 | 22 BOLT (5/8-11X1.125-IN) | 2 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 4T6570 | 23 GUARD | 2 | |
| 8W3694 | 24 GAUGE-FUEL LEVEL | 1 | |
| 1U4508 | 25 COVER AS | 1 | |
| 3B4610 | 26 PIN-COTTER | 1 | |
| 5K9107 | 27 BOLT-LOCKING (3/8-16X0.75-IN) | 4 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 4D6082 | 28 BOLT (1/2-13X1.5-IN) | 1 | |
| 9S0201 | WASHER (13.5X22X2.5-MM THK) | 1 | |
| 2A1538 | 29 BOLT (3/4-10X2.25-IN) | 36 | |
| 2J3506 | 30 NUT-FULL (3/4-10-THD) | 28 | |
| 5P8248 | 31 WASHER-HARD (20X36.5X3.5-MM THK) | 64 | |
| 4T9532 | 32 CABLE AS | 2 | |
| 0310224 | 33 BOLT-LOCKING (3/4-10X1.75-IN) | 4 | |
| 4T7115 | 34 FENDER AS (RH) | 1 | |
| 4T7116 | FENDER AS (LH) | 1 | |
| 4T7112 | 35 BRACKET AS | 2 | |
| 4T7119 | 36 BRACKET (RH) | 1 | |
| 4T7120 | 37 BRACKET (LH) | 1 | |
| 0L1329 | 38 BOLT (1/2-13X3-IN) | 1 | |
| 7J5414 | 39 PIN AS | 1 | |
| 3J2910 | SPACER (46X73X15-MM THK) | 1 | |
| 4T0712 | 40 PLATE (LH) | 1 | |
| 4T0711 | PLATE (RH) | 1 | |
| 5K8454 | 41 BOLT (1/2-13X1.12-IN) | 4 | |
| 1D4585 | 42 BOLT (5/8-11X3.25-IN) | 26 | |
| 8P6640 | 43 WASHER-HARD (17X54X3-MM THK)(3MM) | 24 | |
| 4T3719 | 44 ADAPTER | 26 | |
| 1U0097 | 45 COVER AS | 1 | |
| 4T3891 | 46 PLATE | 3 | |
| 5P7197 | WASHER (17X45X6-MM THK)(6MM) | 8 | |
| 5B0841 | 47 BOLT (5/8-18X1.75-IN) | 2 | |
| 8W5201 | 48 PLATE AS | 1 | |
| 1A4273 | 49 BOLT (5/8-18X1.25-IN) | 4 | |
| 1U0026 | 50 PLATE | 1 | |
| 8W0074 | 51 STEP AS | 2 | |
| 1K6872 | 52 LOCKNUT (1/2-13-THD) | 8 | |
| 7B3235 | BOLT (1/2-13X1.375-IN) | 8 |
