System And Components
3N-2755 BELT TIGHTENER GPFOR USE AS A FAN DRIVE BELT TIGHTENER WHEN ALTERNATOR IS NOT USED
Group No: 3N-2755
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8S4183 | 1 STRAP | 1 | |
| 1F1560 | 2 SPACER (0.531X1X1.75-IN THK) | 1 | |
| 0V0375 | 3 BOLT (1/2-13X3.25-IN) | 1 | |
| 2M0849 | WASHER-HARD (13.5X25.5X5-MM THK) | 1 | |
| 3B8485 | 4 ELBOW (BELT TIGHTENER) | 1 | |
| 2N1334 | 5 BRACKET AS | 1 | |
| 4J9683 | 6 SPACER (0.56X1X1.5-IN THK) | 1 | |
| 1F7958 | 7 NUT-FULL (1/2-13-THD) | 1 | |
| 2H6488 | 8 BOLT (1/2-13X5-IN) | 1 | |
| 0S1588 | 9 BOLT (3/8-16X1.25-IN) | 1 | |
| 9S8752 | 10 NUT-FULL (3/8-16-THD) | 2 | |
| 0S1619 | 11 BOLT (3/8-16X3-IN) | 1 | |
| 3N2705 | 12 BRACKET-MOUNTING | 1 | |
| 2N1331 | 13 PULLEY | 1 | |
| 5M9788 | 14 LOCKNUT-JAM (1/2-20-THD) | 1 | |
| 0310215 | 15 BOLT-LOCKING (1/4-20X0.625-IN) | 3 | |
| 4B4550 | 16 FITTING-PRESSURE RELIEF (1/8-27 PTF) | 1 | |
| 2N1983 | 17 PLATE | 1 | |
| 2N1330 | GASKET | 1 | |
| 4B4280 | 18 WASHER (13.5X27X2.5-MM THK) | 1 | |
| 3K9879 | 19 RING-RETAINING | 1 | |
| 6B0924 | 20 BALL BEARING | 2 | |
| 2B0050 | 21 SEAL-LIP TYPE | 1 | |
| 0S1591 | 22 BOLT (3/8-16X1.5-IN) | 1 | |
| 8M9024 | WASHER-HARD (10.2X22.5X5-MM THK) | 1 | |
| 5M2894 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 |
