System And Components
8N-0224 CYLINDER HEAD GPS/N 10E587-UP
Group No: 8N-0224
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A4429 | 1 LOCK-RETAINER | 16 | |
| 1W5300 | 2 ROTOCOIL AS | 8 | |
| 6N7174 | 3 SHIELD-OIL | 1 | |
| 1007860 | 4 VALVE-INLET | 4 | |
| 1487455 | 5 VALVE-EXHAUST | 4 | |
| 4P8915 | 6 GASKET-CYLINDER HEAD | 1 | |
| 3S5496 | 7 SEAL-O-RING | 1 | |
| 9Y1798 | 8 SEAL | 12 | |
| 7N8018 | 9 SEAL | 4 | |
| 7S7144 | 10 SPRING-VALVE | 8 | |
| 1487425 | 11 GUIDE-VALVE | 8 | |
| 8T6762 | 12 PLUG-PIPE (1/2-14-THD) | 3 | |
| 8T6763 | 13 PLUG-PIPE (1/4-18-THD) | 1 | |
| 3S8313 | 14 PLUG-CUP | 4 | |
| 3B0623 | 15 PLUG-CUP (25.73-MM OD) | 4 | |
| 1070265 | 16 INSERT-VALVE SEAT (EXHAUST) | 4 | |
| 1070268 | 17 INSERT-VALVE SEAT (INLET) | 4 | |
| 3P1896 | 18 PLUG-CUP (35.31-MM OD) | 9 |
