System And Components
3N-7019 DRIVE GP-FANCENTER IS 6.48 INCH OUT FROM HEAD, CRANK CENTER TO FAN VARIES FROM 13 TO 22 INCH, ADJUSTABLE
Group No: 3N-7019
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2B0947 | 1 BOLT (1/2-13X2.25-IN) | 4 | |
| 9F8885 | 2 SPACER (13.5X24X22.2-MM THK) | 4 | |
| 1P9945 | 3 BRACKET AS-FAN | 1 | |
| 1P9946 | SHAFT-FAN | 1 | |
| 5B5812 | DOWEL | 1 | |
| 3B8489 | 4 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 5S2106 | 5 SEAL-LIP TYPE | 1 | |
| 8H9789 | 6 BALL BEARING | 1 | |
| 2P1757 | 7 HUB-FAN PULLEY | 1 | |
| 3L1425 | 8 BALL BEARING | 1 | |
| 5S7264 | 9 WASHER-RETAINING (0.219-IN THK) | 1 | |
| 6V4626 | 10 BOLT-LOCKING (5/16-24X2-IN) | 2 | |
| 8N5305 | 11 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 5S9062 | 12 SPACER (35.032X50.8X15.88-MM THK) | 1 |
