System And Components
8N-3002 AIR CLEANER GPAN ATTACHMENT
Group No: 8N-3002
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3H0976 | 1 SEAL-O-RING | 1 | |
| 6N3686 | 2 AIR CLEANER GP | 1 | |
| 8T9367 | 3 BOLT (1/4-20X2-IN) | 2 | |
| 6V8185 | NUT (1/4-20-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 9B7237 | 4 BOLT (3/8-16X1.25-IN) | 2 | |
| 8T4896 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8N2998 | 6 PIPE-AIR TRANSFER | 1 | |
| 3E7404 | 7 CLAMP-HOSE | 2 | |
| 5P1263 | 8 HOSE (7.62CM) | ||
| 7X0295 | 9 BOLT (3/8-16X5.25-IN) | 1 | |
| 8T4122 | 10 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 8N8724 | 11 BRACKET AS-SUPPORT | 1 | |
| 8T7008 | 12 BOLT (3/8-16X3-IN) | 2 | |
| 6V8801 | NUT (3/8-16-THD) | 2 | |
| 4N9578 | 13 BRACKET AS-AIR CLEANER | 1 | |
| 5L7875 | 14 BAND-AIR CLEANER | 2 | |
| 5L7874 | 15 SCREEN-AIR INLET (AIR CLEANER) | 1 | |
| 5M6214 | 16 PLUG (1/8-27 PTF) | 1 | |
| 7X0345 | 17 BOLT (5/8-11X1.75-IN) | 2 | |
| 7X0515 | WASHER-HARD (17X35X5-MM THK) | 2 |
