System And Components
8N-8832 AIR CLEANER GPHEAVY DUTY
Group No: 8N-8832
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P3408 | 1 CAP AS | 1 | |
| 2S6605 | 2 AIR CLEANER AS | 1 | |
| 2S6606 | BODY AS-UPPER | 1 | |
| 7M1674 | SCREEN-AIR CLEANER INLET (AIR CLEANER) | 1 | |
| 9F2247 | PLUG-PIPE (1/8-27-THD) | 1 | |
| 2S4706 | 3 ROD AS | 4 | |
| 2M0880 | 4 GASKET | 1 | |
| 1S4757 | 5 NUT-WING | 3 | |
| 3S9606 | 6 FILTER ELEMENT AS-AIR (PRIMARY) | 1 | |
| 9M6374 | 7 BODY AS-LOWER | 1 | |
| 9M6381 | 8 RING-LOCK | 1 | |
| 2S4706 | 9 ROD AS | 2 | |
| 2M0879 | 10 SEAL-O-RING | 1 | |
| 2M0881 | 11 CUP AS | 1 | |
| 6F7301 | 12 GASKET | 1 | |
| 1B4205 | 13 NUT (1/2-20-THD) | 4 | |
| 3H7654 | WASHER-HARD (13.5X22.5X3-MM THK) | 4 | |
| 8L4292 | 14 SUPPORT AS | 1 | |
| 0S1591 | 15 BOLT (3/8-16X1.5-IN) | 4 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 7L2031 | 17 SEAL-O-RING | 1 | |
| 0S1588 | 18 BOLT (3/8-16X1.25-IN) | 2 | |
| 5P1263 | 19 HOSE (7.62CM) | ||
| 5P0598 | 20 CLAMP-HOSE | 2 | |
| 1A2029 | 21 BOLT (3/8-16X1.125-IN) | 2 | |
| 5N3904 | 22 SUPPORT AS-AIR CLEANER | 1 | |
| 6L3773 | 23 PIPE-AIR TRANSFER | 1 | |
| 1D4717 | 24 NUT (3/8-16-THD) | 2 | |
| 1Y7945 | 25 STUD | 2 | |
| 0L1704 | 26 STUD | 2 | |
| 2N3322 | 27 GAUGE GP-AIR CLEANER | 1 | |
| 0S1595 | 28 BOLT (1/2-13X1.25-IN) | 2 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6B0933 | 29 SPACER (10.31X19.05X6.35-MM THK) | 2 | |
| 8N2998 | 30 PIPE-AIR TRANSFER | 1 | |
| 1N3367 | 31 SUPPORT AS-PIPE | 1 | |
| 0S1589 | 32 BOLT (5/8-11X1.75-IN) | 2 | |
| 8D5054 | WASHER-HARD (17X30X3-MM THK) | 2 |
