System And Components
2W-1953 TURBOCHARGER GPS/N 10E2395-UP
Group No: 2W-1953
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N6860 | 1 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 4N6861 | WHEEL-COMPRESSOR | 1 | |
| 4N6863 | 2 PLATE AS-BACKING | 1 | |
| 1P1111 | 3 BEARING-THRUST | 1 | |
| 1P1120 | 4 RING-SEAL | 1 | |
| 1P1114 | 5 BEARING-TURBOCHARGER | 2 | |
| 2P9635 | 6 HOUSING AS-CENTER | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 7W2370 | RING-SEAL | 1 | |
| 7N0012 | 7 SHROUD | 1 | |
| 1555236 | 8 SHAFT AS-TURBINE | 1 | |
| 7N6609 | 9 RING-PISTON | 1 | |
| 2P9607 | 10 RING-RETAINING | 4 | |
| 2A0762 | 11 BOLT (1/4-20X0.625-IN) | 4 | |
| 1P1117 | PLATE-LOCK | 2 | |
| 1P1124 | 12 RING-PISTON | 1 | |
| 1P1123 | 13 COLLAR-THRUST | 1 | |
| 1555237 | 14 NUT | 1 | |
| 1C0569 | 16 BOLT (5/16-18X0.5-IN) | 6 | |
| 4N6864 | 17 CLAMP (COMPRESSOR) | 3 | |
| 4N6865 | LOCK-PLATE | 3 | |
| 8N4782 | 18 HOUSING | 1 | |
| 1P1112 | 19 CLAMP (TURBINE) | 3 | |
| 1P1113 | LOCK-PLATE | 3 | |
| 4N6862 | 20 HOUSING-COMPRESSOR | 1 | |
| 6V2489 | 21 BOLT-HIGH TEMPERATURE | 6 | |
| 2W0716 | KIT-TURBOCHARGER REPAIR | 1 |
