System And Components
7N-4651 TURBOCHARGER GPPART OF 2W-0413, 7N-4650 TURBOCHARGER GP
Group No: 7N-4651
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N6860 | 1 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 4N6861 | WHEEL-COMPRESSOR | 1 | |
| 4N6863 | 2 PLATE AS-BACKING | 1 | |
| 1P1111 | 3 BEARING-THRUST | 1 | |
| 1P1120 | 4 RING-SEAL | 1 | |
| 1P1114 | 5 BEARING-TURBOCHARGER | 2 | |
| 2P9635 | 6 HOUSING AS-CENTER | 1 | |
| 1P1136 | PIN | 2 | |
| 7N0012 | 7 SHROUD | 1 | |
| 1P1116 | 8 WHEEL & SHAFT AS | 1 | |
| 7N6609 | 9 RING-PISTON | 1 | |
| 2P9607 | 10 RING-RETAINING | 4 | |
| 2A0762 | 11 BOLT (1/4-20X0.625-IN) | 4 | |
| 1P1117 | PLATE-LOCK | 2 | |
| 1P1124 | 12 RING-PISTON | 1 | |
| 1P1123 | 13 COLLAR-THRUST | 1 | |
| 1P1125 | 14 LOCKNUT-TURBOCHARGER | 1 | |
| 6V2489 | 16 BOLT-HIGH TEMPERATURE | 6 | |
| 4N6864 | 17 CLAMP (COMPRESSOR) | 3 | |
| 4N6865 | LOCK-PLATE | 3 | |
| 7N1687 | 18 HOUSING | 1 | |
| 1P1112 | 19 CLAMP (TURBINE) | 3 | |
| 1P1113 | LOCK-PLATE | 3 | |
| 4N6862 | 20 HOUSING-COMPRESSOR | 1 | |
| 1C0569 | 21 BOLT (5/16-18X0.5-IN) | 6 | |
| 2W0716 | KIT-TURBOCHARGER REPAIR | 1 |
