System And Components
1W1175 FAN DRIVE GROUP-.485 DRIVE RATIOAN ATTACHMENT
Group No: 1W1175
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4566 | 1 BOLT | 2 | |
| 7D1649 | 2 WASHER | 4 | |
| 4N2372 | 3 ADAPTER-BRACKET | 1 | |
| 9L4238 | 4 BOLT | 1 | |
| 4B4550 | 5 FITTING-RELIEF | 1 | |
| 5S2106 | 6 SEAL-LIP TYPE | 1 | |
| 8H9789 | 7 BALL BEARING | 1 | |
| 4N6288 | 8 PULLEY-FAN | 1 | |
| 7N8827 | 9 HUB | 1 | |
| 5S7264 | 10 WASHER-RETAINING 42.93MM(1.69IN)OD | 1 | |
| 7N2900 | WASHER-RETAINING 47.63MM(1.88IN)OD | 1 | |
| 1H5403 | 11 BOLT 50.8MM(2IN)LONG | 2 | |
| 5P7979 | BOLT-SELF LOCKING 57.15MM(2.25IN)LONG | 2 | |
| 6N6598 | 12 ADAPTER-FAN | 1 | |
| 1B5174 | 13 PLUG-PIPE | 1 | |
| 3L1425 | 14 BALL BEARING | 1 | |
| 9F4446 | 15 SEAL-O-RING | 1 | |
| 4N2368 | 16 BRACKET-FAN ADJUSTMENT | 1 | |
| 0L2070 | 17 BOLT | 6 | |
| 2P2243 | 18 SPACER | 1 | |
| 6N6490 | 19 BRACKET AS-FAN | 1 | |
| 4N0684 | 20 PIN-DOWEL | 1 | |
| 5S9062 | 21 SPACER | 1 | |
| 2P9084 | 22 STUD-TAPERLOCK | 2 | |
| 1D4719 | NUT | 2 | |
| 0S1594 | 23 BOLT | 2 | |
| 2D4867 | 24 FITTING-HYDRAULIC | 1 |
