System And Components
7N8833 DRIVE GP-FAN-TYPE 1REFER TO 4N6973 RADIATOR CHART-PAGE 93
Group No: 7N8833
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1A2029 | 1 BOLT | 2 | |
| 9N5120 | 2 BRACKET-ADJUSTABLE | 1 | |
| 1D4566 | 3 BOLT | 2 | |
| 1F7960 | 4 WASHER | 4 | |
| 8L5213 | 5 BOLT | 1 | |
| 5S9062 | 6 SPACER | 1 | |
| 8H9789 | 7 BALL BEARING | 1 | |
| 0L2070 | 8 BOLT | 6 | |
| 5S7264 | 9 WASHER-RETAINING 42.93MM(1.69IN)OD | 1 | |
| 7N2900 | WASHER-RETAINING 47.63MM(1.88IN)OD | 1 | |
| 1H5403 | 10 BOLT 50.8MM(2IN)LONG | 2 | |
| 5P7979 | BOLT-SELF LOCKING 57.15MM(2.25IN)LONG | 2 | |
| 4N2370 | 11 ADAPTER-FAN | 1 | |
| 1B5174 | 12 PLUG-PIPE | 1 | |
| 3L1425 | 13 BALL BEARING | 1 | |
| 9F4446 | 14 SEAL-O-RING | 1 | |
| 2P2243 | 15 SPACER | 1 | |
| 7N8827 | 16 HUB | 1 | |
| 4N2532 | 17 V-BELT SET (2 BELTS) | 1 | |
| 6N0597 | 18 PULLEY-FAN | 1 | |
| 5S2106 | 19 SEAL-LIP TYPE | 1 | |
| 6N7688 | 20 BRACKET AS-FAN | 1 | |
| 4N0684 | 21 PIN-DOWEL | 1 | |
| 4B4550 | 22 FITTING-RELIEF | 1 | |
| 4N2372 | 23 ADAPTER-BRACKET | 1 | |
| 2P9084 | 24 STUD-TAPERLOCK | 2 | |
| 1D4719 | NUT | 2 | |
| 2D4867 | 25 FITTING-HYDRAULIC | 1 |
