System And Components
7N8968 FAN DRIVE GROUPREFER TO 4N6973 RADIATOR CHART-PAGE 93
Group No: 7N8968
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4566 | 1 BOLT (1/2-13X3.5IN) | 2 | |
| 1F7960 | 2 WASHER | 4 | |
| 4N2372 | 3 ADAPTER-BRACKET | 1 | |
| 8L5213 | 4 BOLT | 1 | |
| 1F7958 | 5 NUT-FULL (1/2-13 THD) | 2 | |
| 5S2106 | 6 SEAL-LIP | 1 | |
| 8H9789 | 7 BALL BEARING | 1 | |
| 6N0597 | 8 PULLEY-FAN DRIVE | 1 | |
| 7N8827 | 9 HUB | 1 | |
| 5S7264 | 10 WASHER-RETAINING (42.93MM(1.69IN)OD) | 1 | |
| 7N2900 | WASHER-RETAINING (47.63MM(1.88IN)OD) | 1 | |
| 1H5403 | 11 BOLT (50.8MM(2IN)LONG) | 2 | |
| 5P7979 | BOLT-LOCKING (57.15MM(2.25IN)LONG) | 2 | |
| 4N2371 | 12 ADAPTER-FAN | 1 | |
| 7X7731 | 13 PLUG-PIPE (3/4-14 NPTF THD) | 1 | |
| 3L1425 | 14 BALL BEARING | 1 | |
| 9F4446 | 15 SEAL-O-RING (78.74MM ID) | 1 | |
| 4N2532 | 16 V-BELT SET | 1 | |
| 0L2070 | 17 BOLT (3/8-16X2.25IN) | 6 | |
| 2P2243 | 18 SPACER | 1 | |
| 6N7688 | 19 BRACKET AS-FAN | 1 | |
| 4N0684 | 20 DOWEL | 1 | |
| 1P9946 | 21 SHAFT-FAN | 1 | |
| 5S9062 | 22 SPACER | 1 | |
| 4B4550 | 23 FITTING-RELIEF (1/8-27 PTF) | 1 | |
| 2P9084 | 24 STUD-TAPERLOCK | 2 | |
| 1A2029 | 25 BOLT (3/8-16X1.125IN) | 2 | |
| 9N5120 | 26 BRACKET-ADJUSTMENT | 1 | |
| 2D4867 | 27 FITTING-HYDRAULIC | 1 |
