System And Components
4N6700 TURBOCHARGER GP-(4N6701 N/S)*R
Group No: 4N6700
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N9538 | 1 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 5S4555 | NUT | 1 | |
| 9N0146 | 2 WHEEL | 1 | |
| 5S4556 | 3 INSERT | 1 | |
| 5S4546 | 4 RING-RETAINING | 1 | |
| 5S4548 | 5 SEAL-O-RING | 1 | |
| 5S4554 | 6 SEAL-O-RING | 1 | |
| 8S9223 | 7 BEARING-THRUST | 1 | |
| 5S4550 | 8 RING-THRUST | 2 | |
| 5S4557 | 9 BEARING | 2 | |
| 4M6983 | 10 RING-RETAINING | 4 | |
| 4N9540 | 11 HOUSING AS-CENTER | 1 | |
| 5S5199 | PIN-GROOVE | 2 | |
| 4N9556 | 12 SHROUD | 1 | |
| 4M6990 | 13 RING-SNAP | 1 | |
| 5S4551 | 14 SLEEVE-OIL CONTROL | 1 | |
| 4N7595 | 15 RING | 1 | |
| 9S8993 | 16 WHEEL AS-TURBINE | 1 | |
| 8S9222 | 17 SLEEVE | 1 | |
| 4M8013 | 18 RING-PISTON | 2 | |
| 5S4547 | 19 SLEEVE-SPACER | 1 | |
| 5S4549 | 20 DEFLECTOR-OIL | 1 | |
| 8H3710 | 21 SCREW-TAPPING | 2 | |
| 1W4795 | 22 NAMEPLATE | 1 | |
| 5S4517 | 23 CLAMP AS | 1 | |
| 7M9918 | NUT-SELF LOCKING | 1 | |
| 4N6699 | 24 HOUSING-TURBINE | 1 | |
| 1S4295 | 25 GASKET-TURBOCHARGER | 1 | |
| 2N2765 | 26 BOLT-HIGH TEMP | 4 | |
| 2N2766 | LOCKNUT | 4 | |
| 9N0608 | 27 COVER-COMPRESSOR | 1 | |
| 5S4558 | 28 CLAMP AS-COMPRESSOR | 1 | |
| 7M9918 | NUT-SELF LOCKING | 1 | |
| 2W0725 | KIT-CARTRIDGE (INCLUDES | 1 |
