System And Components
1N2992 AIR COMPRESSOR GP*RTYPE 1
Group No: 1N2992
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7H3171 | 1 PLUG-PIPE | 1 | |
| 3J5390 | 2 PLUG | 5 | |
| 0S1615 | 3 BOLT | 6 | |
| 3B4504 | LOCKWASHER | 6 | |
| 3B4505 | 4 LOCKWASHER | 6 | |
| 9M0379 | 5 BOLT | 10 | |
| 2B0858 | 6 PLUG-PIPE | 1 | |
| 2W5133 | 7 CYLINDER HEAD AS | 1 | |
| 2H3755 | 8 BOLT | 2 | |
| 2A0954 | 9 COVER-OUTLET | 1 | |
| 1S7107 | GASKET | 1 | |
| 2S3079 | 10 COVER-AIR COMPENSATOR | 1 | |
| 3H5175 | GASKET | 1 | |
| 9L2276 | 11 GUIDE-VALVE | 2 | |
| 9L2277 | VALVE-INLET | 2 | |
| 9L2278 | 12 SPRING-VALVE | 2 | |
| 9N2855 | 13 GASKET-CYLINDER HEAD | 1 | |
| 9N5449 | 14 CYLINDER BLOCK AS | 1 | |
| 3H7311 | 15 GASKET-CYLINDER BLOCK | 1 | |
| 2S4013 | 16 COVER AS-END | 1 | |
| 2S4245 | BEARING-SLEEVE | 1 | |
| 1B8714 | 17 KEY-WOODRUFF | 1 | |
| 9L1517 | 18 WASHER-THRUST | 1 | |
| 0S1617 | 19 BOLT | 4 | |
| 2H3931 | 20 SEAL-O-RING | 1 | |
| 1N2994 | 21 CRANKCASE AS | 1 | |
| 1S9867 | 22 BEARING-SLEEVE | 1 | |
| 0S1594 | 23 BOLT | 6 | |
| 3B4506 | LOCKWASHER | 6 | |
| 9L1518 | 24 WASHER-THRUST | 1 | |
| 1N2993 | 25 CRANKSHAFT-COMPRESSOR | 1 | |
| 2W6045 | KIT-PISTON RINGS | 1 | |
| 2W6044 | KIT-AIR COMPRESSOR | 1 |
