System And Components
4W-4399 LINES GP-AIRS/N 48W20071-UP
Group No: 4W-4399
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N0879 | 1 CLAMP | 4 | |
| 9Y2148 | 2 TUBE AS-EXHAUST | 1 | |
| 9Y2149 | 3 TUBE AS-EXHAUST | 1 | |
| 1333565 | 4 TUBE AS-EXHAUST | 1 | |
| 1333566 | 5 TUBE AS-EXHAUST | 1 | |
| 1069408 | 6 SEAL-EXHAUST | 2 | |
| 1W0481 | RING-EXHAUST SEAL | 2 | |
| 8N0878 | CLAMP | 2 | |
| 7E3205 | 7 MANIFOLD-INLET | 1 | |
| 5P2755 | 8 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN) | 4 | |
| 4W4314 | 9 SUPPORT-TURBOCHARGER | 1 | |
| 0S1571 | 10 BOLT (3/8-16X1.75-IN) | 3 | |
| 9S8752 | 11 NUT-FULL (3/8-16-THD) | 5 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 | |
| 8N4823 | 13 SUPPORT AS | 1 | |
| 0L1352 | 14 BOLT (3/8-16X3.25-IN) | 6 | |
| 0L2070 | 15 BOLT (3/8-16X2.25-IN) | 2 | |
| 1A2029 | 16 BOLT (3/8-16X1.125-IN) | 5 | |
| 9M1974 | 17 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6765 | 18 PLUG-PIPE (1/4-18-THD) | 1 | |
| 4L8337 | 19 SEAL-O-RING | 4 | |
| 4W7062 | 20 ADAPTER | 1 | |
| 1299416 | GASKET | 1 | |
| 8N2574 | 21 BRACKET | 1 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 2 | |
| 1C2251 | 23 BOLT (3/8-16X1.87-IN) | 2 | |
| 4W1073 | 24 TUBE-AIR | 1 | |
| 0S0509 | 25 BOLT (3/8-16X0.75-IN) | 2 | |
| 7W1944 | RETAINER | 2 | |
| 5B7890 | 26 PLUG-PIPE | 2 | |
| 0S1588 | 27 BOLT (3/8-16X1.25-IN) | 3 | |
| 1W6186 | 28 SHIELD AS | 1 | |
| 5P9959 | 29 BOLT (5/16-18X0.5-IN) | 2 | |
| 8N2258 | 30 SHIELD AS-BOTTOM | 1 |
