Assembly
100%

2W-6636 SHIELD GP-MANIFOLDS/N 6MB91-UP

Group No: 2W-6636
Part NumberPart NameQty
5K09061 BOLT (5/16-18X0.625-IN)21
8T42242 WASHER-HARD (8.8X16X2-MM THK)49
8N23683 SHIELD AS1
4M64254 BOLT (5/16-18X1-IN)2
5P4116WASHER-HARD (8.8X20.5X2-MM THK)2
6V81895 NUT (5/16-18-THD)28
1N33006 SHIELD AS4
8N15947 SHIELD AS2
6V27128 STUD12
8N16229 SHIELD AS-MANIFOLD (RH)1
8N161610 SHIELD AS2
8N161911 SHIELD AS2
4L645412 BOLT (3/8-16X1-IN)8
8T891913 BOLT (1/2-13X1.75-IN)2
8T4223WASHER-HARD (13.5X25.5X3-MM THK)2
8N795314 PLATE1
8N162015 SHIELD AS-MANIFOLD (LH)1
6V880116 NUT (3/8-16-THD)3
1N473417 CLAMP2
2P091118 ANGLE1
8N795419 PLATE2
8T539120 BOLT (5/16-18X0.5-IN)4
5P411621 WASHER-HARD (8.8X20.5X2-MM THK)6
8N161422 PLATE2
4L645923 BOLT (3/8-16X2.5-IN)1
8T489624 WASHER-HARD (10.2X18.5X2.5-MM THK)14
8J411025 CLAMP2
9B723726 BOLT (3/8-16X1.25-IN)2
7V240027 STRIP2
8T539128 BOLT (5/16-18X0.5-IN)2
8T422429 WASHER-HARD (8.8X16X2-MM THK)2
1W618530 SHIELD AS1
2W142631 PLATE1
8T483532 BOLT (1/2-13X2-IN)2
8T4223WASHER-HARD (13.5X25.5X3-MM THK)2
