7N-7032 SHIELD GP-MANIFOLDS/N 6MB61-UP

Group No: 7N-7032
Part NumberPart NameQty
1C05691 BOLT (5/16-18X0.5-IN)15
9M19742 WASHER-HARD (8.8X16X2-MM THK)51
8N23683 SHIELD AS1
2H37554 BOLT (5/16-18X0.43-IN)8
1B53545 NUT-FULL (5/16-18-THD)28
1N33006 SHIELD AS4
8N15947 SHIELD AS2
6V27128 STUD12
8N16229 SHIELD AS-MANIFOLD (RH)1
8N161610 SHIELD AS2
8N161911 SHIELD AS2
0S159412 BOLT (3/8-16X1-IN)8
5M2894WASHER-HARD (10.2X18.5X2.5-MM THK)8
8N161413 PLATE2
0S158714 BOLT (1/2-13X1.75-IN)4
5P8245WASHER-HARD (13.5X25.5X3-MM THK)4
8N795315 PLATE1
8N162016 SHIELD AS-MANIFOLD (LH)1
5P995917 BOLT (5/16-18X0.5-IN)6
4B427718 WASHER (8.8X17.5X1.6-MM THK)4
8N795419 PLATE2
1W618520 SHIELD AS1
9M197421 WASHER-HARD (8.8X16X2-MM THK)2
1W038522 BRACKET1
