System And Components
4T-7659 BOWL GP-SCRAPERS/N 6MB82-90
Group No: 4T-7659
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6J5953 | 1 PIN | 2 | |
| 4J5193 | 2 PIN | 2 | |
| 0L1178 | 3 BOLT (3/4-10X2-IN) | 2 | |
| 5K9107 | 4 BOLT-LOCKING (3/8-16X0.75-IN) | 4 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 4D6082 | 6 BOLT (1/2-13X1.5-IN) | 1 | |
| 9S0201 | 7 WASHER (13.5X22X2.5-MM THK) | 1 | |
| 3B4610 | 8 PIN-COTTER | 1 | |
| 5P8248 | 9 WASHER-HARD (20X36.5X3.5-MM THK) | 64 | |
| 2J3506 | 10 NUT-FULL (3/4-10-THD) | 28 | |
| 2A1538 | 11 BOLT (3/4-10X2.25-IN) | 36 | |
| 4T7115 | 12 FENDER AS (RH) | 1 | |
| 6C3680 | RIVET-POP | 24 | |
| 8W0527 | TREAD AS | 1 | |
| 8W5190 | HANDLE | 1 | |
| 0388454 | BAR | 1 | |
| 4T7116 | 13 FENDER AS (LH) | 1 | |
| 6C3680 | RIVET-POP | 24 | |
| 8W0527 | TREAD AS | 1 | |
| 8W5190 | HANDLE | 1 | |
| 0388454 | BAR | 1 | |
| 4T7119 | 14 BRACKET (RH) | 1 | |
| 4T7120 | 15 BRACKET (LH) | 1 | |
| 4T7112 | 16 BRACKET AS | 2 | |
| 0310224 | 17 BOLT-LOCKING (3/4-10X1.75-IN) | 4 | |
| 4T9532 | 18 CABLE AS | 2 | |
| 1U0026 | 19 PLATE | 1 | |
| 1D4585 | 20 BOLT (5/8-11X3.25-IN) | 26 | |
| 8P6640 | 21 WASHER-HARD (17X54X3-MM THK) | 24 | |
| 4T3719 | 22 ADAPTER | 26 | |
| 1A4273 | 23 BOLT (5/8-18X1.25-IN) | 4 | |
| 1U0097 | 24 COVER AS | 1 | |
| 4T3891 | 25 PLATE | 3 | |
| 5K8454 | 29 BOLT (1/2-13X1.12-IN) | 4 | |
| 5P8245 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 22 | |
| 4T0711 | 31 PLATE (RH) | 1 | |
| 4T0712 | 32 PLATE (LH) | 1 | |
| 4T7683 | 33 BOWL AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3D2365 | CLIP | 10 | |
| 8W4879 | FRAME AS-BOWL | 1 | |
| 8W4948 | BOWL AS | 1 | |
| 5C3162 | BLOCK | 2 | |
| 5H6106 | LUG | 1 | |
| 8W1247 | RAIL AS | 2 | |
| 8X3714 | TRACK AS (RH) | 1 | |
| 8X3715 | TRACK AS (LH) | 1 | |
| 8J5178 | 34 BLOCK | 1 | |
| 4T7747 | 35 PIN AS | 1 | |
| 3J2910 | SPACER (46X73X15-MM THK) | 1 | |
| 0L1329 | 36 BOLT (1/2-13X3-IN) | 1 | |
| 4T1473 | 37 CLAMP | 1 | |
| 4T1474 | 38 CLAMP | 1 | |
| 1D4569 | 39 BOLT (1/2-13X4.25-IN) | 2 | |
| 4T6570 | 40 GUARD | 2 | |
| 7S9372 | 41 BOLT (5/8-11X1.125-IN) | 2 | |
| 5P8247 | 42 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 7B3235 | 43 BOLT (1/2-13X1.375-IN) | 8 | |
| 1K6872 | 44 LOCKNUT (1/2-13-THD) | 8 | |
| 8W0074 | 45 STEP AS | 2 | |
| 1U4508 | 46 COVER AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 7D7261 | HANDHOLD | 1 | |
| 5P7197 | 47 WASHER (17X45X6-MM THK) | 8 | |
| 8W3694 | 48 GAUGE-FUEL LEVEL | 1 | |
| 5B0841 | 49 BOLT (5/8-18X1.75-IN) | 2 | |
| 8W5201 | 50 PLATE AS | 1 |
