System And Components
8W-4947 BOWL GP-SCRAPERS/N 6MB91-96
Group No: 8W-4947
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8W4948 | 1 BOWL AS | 1 | |
| 3J2849 | 2 RIB (RH) | 1 | |
| 3J2850 | RIB (LH) | 1 | |
| 8W5916 | 3 TRACK AS | 1 | |
| 8W5917 | TRACK AS | 1 | |
| 3D2365 | 4 CLIP | 10 | |
| 1U4100 | 5 HOOK-RETRIEVAL | 2 | |
| 1U4217 | 6 PLATE | 1 | |
| 1F0748 | 7 NUT-WELD (1/2-13-THD) | 2 | |
| 8W5003 | 8 REINFORCEMENT | 1 | |
| 8W5004 | REINFORCEMENT | 1 | |
| 8W4993 | 9 PLATE | 1 | |
| 8W4992 | 10 PLATE | 1 | |
| 9F2978 | 11 NUT-WELD (3/8-16-THD) | 1 | |
| 7J5544 | 12 FITTING (3/4X16-THD) | 3 | |
| 6G3154 | 13 PLATE | 1 | |
| 2J7792 | 14 SPACER | 1 | |
| 8F9836 | 15 BOSS (3/8-16-THD) | 22 | |
| 8W4883 | 16 STEP AS | 2 | |
| 1U1566 | 17 RIB | 4 | |
| 4J5050 | 18 BOSS | 1 | |
| 3Y7829 | 19 BOSS (3/8-16-THD) | 7 | |
| 4V3638 | 20 BOSS | 4 | |
| 5T9703 | 21 PLATE (LH) | 1 | |
| 5T9542 | PLATE (RH) | 1 | |
| 3G8344 | 22 SPACER | 2 | |
| 5C3162 | 23 BLOCK | 2 | |
| 9D1205 | 24 BLOCK | 1 | |
| 8J7574 | 25 LUG | 1 | |
| 8D7729 | 26 BOSS (3/8-16X0.81-IN) | 2 | |
| 6M4263 | 27 BOSS | 3 | |
| 4J3818 | 28 BLOCK-TAPPED | 1 | |
| 4D7529 | 29 BOSS (3/8-16-THD) | 5 | |
| 2G7492 | 30 LUG | 1 | |
| 5H6106 | 31 LUG | 1 | |
| 3G7106 | 32 PLATE | 2 | |
| 2D1641 | 33 LUG | 1 | |
| 4T7115 | 34 FENDER AS (RH) | 1 | |
| 4T7116 | FENDER AS (LH) | 1 | |
| 8W5190 | 35 HANDLE | 1 | |
| 4T7119 | 36 BRACKET (RH) | 1 | |
| 4T7120 | BRACKET (LH) | 1 | |
| 8W4846 | 37 BRACKET AS | 2 | |
| 0L1329 | 38 BOLT (1/2-13X3-IN) | 1 | |
| 4T7747 | 39 PIN AS | 1 | |
| 3J2910 | SPACER (46X73X15-MM THK) | 1 | |
| 4T0712 | 40 PLATE (LH) | 1 | |
| 4T0711 | PLATE (RH) | 1 | |
| 5K8454 | 41 BOLT (1/2-13X1.12-IN) | 4 | |
| 1D4585 | 42 BOLT (5/8-11X3.25-IN) | 26 | |
| 8P6640 | 43 WASHER-HARD (17X54X3-MM THK) | 24 | |
| 4T3719 | 44 ADAPTER | 26 | |
| 1U0097 | 45 COVER AS | 1 | |
| 4T3891 | 46 PLATE | 3 | |
| 5P7197 | WASHER (17X45X6-MM THK) | 8 | |
| 5B0841 | 47 BOLT (5/8-18X1.75-IN) | 2 | |
| 8W5201 | 48 PLATE AS | 1 | |
| 1A4273 | 49 BOLT (5/8-18X1.25-IN) | 4 | |
| 1U0026 | 50 PLATE | 1 | |
| 8W0074 | 51 STEP AS | 2 | |
| 1K6872 | 52 LOCKNUT (1/2-13-THD) | 8 | |
| 7B3235 | BOLT (1/2-13X1.375-IN) | 8 | |
| 1D4608 | 53 BOLT (3/4-10X2.75-IN) | 8 | |
| 8J5178 | 54 BLOCK | 1 | |
| 6J5953 | 55 PIN | 2 | |
| 4J5193 | 56 PIN | 2 | |
| 0L1178 | 57 BOLT (3/4-10X2-IN) | 2 | |
| 5P3882 | 58 BOLT-LOCKING (3/4-10X2.25-IN) | 4 | |
| 4T1473 | 59 CLAMP (LARGE HOLE) | 1 | |
| 4T1474 | CLAMP (SMALL HOLE) | 1 | |
| 1D4569 | 60 BOLT (1/2-13X4.25-IN) | 2 | |
| 8T4223 | 61 WASHER-HARD (13.5X25.5X3-MM THK) | 22 | |
| 7S9372 | 62 BOLT (5/8-11X1.125-IN) | 2 | |
| 8T4122 | WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 4T6570 | 63 GUARD | 2 | |
| 8W3694 | 64 GAUGE-FUEL LEVEL | 1 | |
| 1U4508 | 65 COVER AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 4 | |
| 7D7261 | 66 HANDHOLD | 1 | |
| 5M3062 | 67 BOLT (3/8-16X0.75-IN) | 4 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 4D6082 | 68 BOLT (1/2-13X1.5-IN) | 1 | |
| 9S0201 | WASHER (13.5X22X2.5-MM THK) | 1 | |
| 3B4610 | PIN-COTTER | 1 | |
| 2A1538 | 69 BOLT (3/4-10X2.25-IN) | 28 | |
| 2J3506 | 70 NUT-FULL (3/4-10-THD) | 28 | |
| 8T4994 | 71 WASHER-HARD (20X36.5X3.5-MM THK) | 64 | |
| 8W3058 | 72 CABLE AS | 2 |
