System And Components
2W3234 DRIVE GP-FAN
Group No: 2W3234
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N3306 | 1 BRACKET AS-FAN | 1 | |
| 1S9209 | 2 SHAFT-TIGHTENER | 1 | |
| 4N0955 | 3 PIN-DOWEL | 1 | |
| 1B2886 | 4 BOLT | 2 | |
| 5P8245 | 5 WASHER | 4 | |
| 0S1587 | 6 BOLT | 2 | |
| 2P1757 | 7 HUB-FAN PULLEY | 1 | |
| 8N5305 | 8 SPACER | 1 | |
| 3L1425 | 9 BALL BEARING | 1 | |
| 2W2277 | 10 ADAPTER-FAN | 1 | |
| 7N1275 | 11 PULLEY-FAN | 1 | |
| 5N4751 | 12 V-BELT SET (3 BELTS) | 1 | |
| 7F0938 | 13 BOLT | 2 | |
| 7N2900 | 14 WASHER-RETAINING | 1 | |
| 9F4446 | 15 SEAL-O-RING | 1 | |
| 0T0573 | 16 BOLT | 6 | |
| 1D4717 | 17 NUT | 6 | |
| 8H9789 | 18 BALL BEARING | 1 | |
| 5S2106 | 19 SEAL-LIP TYPE | 1 | |
| 5S9062 | 20 SPACER | 1 | |
| 2W0109 | 21 TUBE AS-GREASE | 1 | |
| 8L6557 | 22 CONNECTOR | 2 | |
| 4H8878 | 23 CLIP | 1 | |
| 0S1588 | 24 BOLT | 2 | |
| 5M2894 | 25 WASHER | 2 | |
| 6N4111 | 26 BRACKET AS | 1 | |
| 3B8485 | 27 FITTING-HYDRAULIC | 1 | |
| 3B0551 | 28 PLUG-PIPE | 1 |
