System And Components
1W5082 CYLINDER BLOCK GPENGINE S/N 48W19699-19914
Group No: 1W5082
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N9881 | 1 TUBE AS-OIL JET | 8 | |
| 4N1650 | 2 DOWEL | 4 | |
| 7H3171 | 3 PLUG-PIPE | 4 | |
| 1W5081 | 4 CYLINDER BLOCK AS | 1 | |
| 9F2247 | 5 PLUG | 9 | |
| 6N9133 | 6 GASKET-PLATE | 2 | |
| 4N4178 | 7 PLATE-BLOCK | 2 | |
| 4N0693 | 8 PLUG-TAPERLOCK 38.10MM(1.50IN)OD | 3 | |
| 4N0683 | 9 DOWEL | 4 | |
| 4N9916 | 10 BOLT-OIL JET | 8 | |
| 3B0645 | 11 PLUG-CUP | 1 | |
| 6L4428 | 12 STUD-TAPERLOCK | 3 | |
| 2M9780 | 13 SEAL-O-RING | 4 | |
| 7M7410 | 14 PLUG | 6 | |
| 8M8283 | 15 SEAL-O-RING | 2 | |
| 3S6605 | 16 PLUG-CUP | 2 | |
| 9S4190 | 17 PLUG-0-RING | 4 | |
| 4W6061 | SLEEVE-BOTTOM LINER | NULL | |
| 4W4588 | SLEEVE-LIFTER BORE | NULL | |
| 2W3815 | INSERT-LINER SEAT 1.59MM(.06IN.)THK | NULL | |
| 5N0093 | INSERT-LINER SEAT | NULL |
