System And Components
1037415 LINES GP-AIRENGINE S/N 73W14759-UP
Group No: 1037415
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P5700 | 1 SEAL-O-RING | 8 | |
| 4N8523 | 2 PIPE-OUTLET | 1 | |
| 1228433 | 3 ELBOW-EXHAUST | 1 | |
| 5M2894 | 4 WASHER (2.5MM THK) | 10 | |
| 3B1915 | 5 BOLT (3/8-16X1.375IN) | 8 | |
| 4N1320 | 6 GASKET-ADAPTER | 2 | |
| 7N2771 | 7 COUPLING | 2 | |
| 3E7428 | 8 PLUG-PIPE | 4 | |
| 7N2387 | 9 ELBOW-EXHAUST | 1 | |
| 5L8854 | 10 RING-SEALING | 4 | |
| 4K5175 | 11 BOLT-12 POINT HEAD (1/2-13X1.5IN) | 2 | |
| 2M0849 | 12 WASHER (5MM THK) | 2 | |
| 6N6734 | 13 SUPPORT-HOUSING-RH | 1 | |
| 4N8677 | 14 PIPE-OUTLET | 1 | |
| 4N1849 | 15 PIPE-AIR | 2 | |
| 1332232 | 16 TUBE AS | 1 | |
| 0S1587 | 17 BOLT (1/2-13X1.75IN) | 2 | |
| 4D0672 | 18 DOWEL | 4 | |
| 6N6733 | 19 SUPPORT-HOUSING-LH | 1 | |
| 1228432 | 20 ELBOW-EXHAUST | 1 | |
| 5L9316 | 21 CLAMP | 2 | |
| 6I2855 | 22 TUBE AS | 1 | |
| 1F7958 | 23 NUT-FULL (1/2-13 THD) | 4 | |
| 5P8245 | WASHER (3MM THK) | 4 | |
| 8N0879 | 24 CLAMP | 4 | |
| 0S1587 | 25 BOLT (84.45MM(1.75IN)LG) | 2 | |
| 0S1591 | 26 BOLT (38.10MM(1.5IN)LG) | 2 | |
| 9F8999 | 27 BOLT (3/8-16X7IN) | 1 | |
| 6N7791 | 28 PLATE | 1 | |
| 5B2638 | 29 BOLT (133.35MM(5.25IN)LG) | 2 | |
| 1A5183 | 30 BOLT (120.7MM(4.75IN)LG) | 3 | |
| 2A4639 | 31 BOLT (41.5MM(1.625IN)LG) | 3 | |
| 0L1143 | 32 BOLT (63.5MM(2.5IN)LG) | 9 | |
| 2M8411 | 33 STUD | 1 | |
| 9S8752 | NUT-FULL (3/8-16 THD) | 1 |
