System And Components
7N-8848 DRIVE GP-FAN -BLOWERS/N 78Z1144-4866
Group No: 7N-8848
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5S9062 | 1 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 5S2106 | 2 SEAL-LIP TYPE | 1 | |
| 0L2070 | 3 BOLT (3/8-16X2.25-IN) | 6 | |
| 7N8827 | 4 HUB | 1 | |
| 3L1425 | 5 BALL BEARING | 1 | |
| 2D4867 | 6 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 2 | |
| 6N6598 | 7 ADAPTER-FAN | 1 | |
| 7X7731 | 8 PLUG-PIPE (3/4-14-THD) | 1 | |
| 5P7979 | 9 BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 7N2900 | RETAINER | 1 | |
| 9F4446 | 10 SEAL-O-RING | 1 | |
| 7N8828 | 11 PULLEY-FAN DRIVE (4-GROOVE) | 1 | |
| 1F7958 | 12 NUT-FULL (1/2-13-THD) | 4 | |
| 6N2538 | 13 BRACKET-FAN ADJUSTMENT | 1 | |
| 6N6653 | 14 V-BELT SET (INCLUDES 4-BELTS)(FAN DRIVE) | 1 | |
| 8N5305 | 15 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 8H9789 | 16 BALL BEARING | 1 | |
| 6N7688 | 17 BRACKET AS-FAN | 1 | |
| 1P9946 | SHAFT-FAN | 1 | |
| 4N0684 | DOWEL | 1 | |
| 6U1989 | 18 VALVE-RELIEF (FAN DRIVE) | 1 | |
| 8L5213 | 19 BOLT (3/8-16X4-IN) | 1 | |
| 9S8752 | 20 NUT-FULL (3/8-16-THD) | 1 | |
| 6N2547 | 21 ADAPTER-FAN BRACKET | 1 | |
| 9L0553 | 22 STUD-TAPERLOCK (1/2-13X4.25-IN) | 4 | |
| 1F7960 | WASHER (13.5X32X6-MM THK) | 4 | |
| 0S1594 | 23 BOLT (3/8-16X1-IN) | 2 |
