System And Components
8N-8401 LINES GP-TURBOCHARGER OILS/N 78Z1144-1171
Group No: 8N-8401
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L1351 | 1 BOLT (3/8-16X0.875-IN) | 2 | |
| 3L9689 | WASHER (10.5X25.4X5-MM THK) | 2 | |
| 2B3243 | 2 CLIP | 2 | |
| 9L1321 | 3 STUD-TAPERLOCK (3/8-16X1.18-IN) | 1 | |
| 2N2766 | LOCKNUT (3/8-16-THD) | 1 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 8N0963 | 5 TUBE AS-OIL | 1 | |
| 1S6595 | 6 GASKET-OIL SUPPLY | 1 | |
| 0S1571 | 7 BOLT (3/8-16X1.75-IN) | 2 | |
| 1A2029 | 8 BOLT (3/8-16X1.125-IN) | 2 | |
| 1S4810 | 9 GASKET-OIL DRAIN | 1 | |
| 8N3886 | 10 TUBE AS | 1 | |
| 8N3853 | 11 ADAPTER-DRAIN | 1 | |
| 8N3887 | GASKET | 1 | |
| 9M4849 | 12 SEAL-O-RING | 1 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 4 | |
| 8N2102 | 14 SHIELD AS-HEAT | 1 | |
| 0S0509 | 15 BOLT (3/8-16X0.75-IN) | 2 | |
| 6M7476 | 16 ELBOW | 1 | |
| 2M9780 | 17 SEAL-O-RING | 1 | |
| 1D4717 | 18 NUT (3/8-16-THD) | 3 | |
| 8N8390 | 19 BRACKET | 1 |
