System And Components
4W-7635 CARTRIDGE GP-TURBOCHARGERS/N 78Z1180-4866
Group No: 4W-7635
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N2363 | 1 WHEEL-COMPRESSOR | 1 | |
| 7N3759 | 2 RING-PISTON | 1 | |
| 9N2046 | 3 SPACER-THRUST | 1 | |
| 6N5004 | 4 BEARING-THRUST | 1 | |
| 9M8911 | 5 COLLAR-THRUST | 1 | |
| 9M8919 | 6 RING-SEAL | 2 | |
| 1P1120 | 7 RING-SEAL | 1 | |
| 9M8915 | 8 RING-RETAINING | 3 | |
| 3S4484 | 9 LOCKNUT-TURBOCHARGER (5/16-24-THD) | 1 | |
| 9N2036 | 10 PLATE-LOCK | 4 | |
| 0S1616 | 11 BOLT (1/4-20X1-IN) | 4 | |
| 8N0819 | 12 PLATE AS-BACKING | 1 | |
| 7W0130 | 12A BEARING-THRUST | 1 | |
| 7W0131 | 12B STUD-DRIVE | 3 | |
| 9N2035 | 13 HOUSING AS-CENTER | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 7W2368 | RING-SEAL | 1 | |
| 6N8486 | 14 WHEEL & SHAFT AS | 1 | |
| 9N3701 | 15 SHROUD | 1 | |
| 2W0715 | KIT-CARTRIDGE (TURBOCHARGER) | 1 | |
| 9N2041 | KIT-BEARING | 1 | |
| 7C7446 | KIT-BEARING (0.51-MM OS) | ||
| 7C7447 | KIT-BEARING (0.51-MM OS, 0.25-MM US) | ||
| 7N3194 | KIT-BEARING (0.25-MM OS, 0.25-MM US) | ||
| 8N4157 | KIT-BEARING (0.25-MM OS) | ||
| 8N4160 | KIT-BEARING (0.25-MM US) |
