Assembly
100%

8N-8396 LINES GP-AIRS/N 78Z1144-2172

Group No: 8N-8396
Part NumberPart NameQty
4N61451 SUPPORT-MANIFOLD1
5F48992 BOLT (3/8-16X5.5-IN)1
0L13523 BOLT (3/8-16X3.25-IN)3
0S15914 BOLT (3/8-16X1.5-IN)4
2W75535 MANIFOLD1
5B78906 PLUG-PIPE2
7L05207 STUD-TAPERLOCK (3/8-16X1.968-IN)4
2N27668 LOCKNUT (3/8-16-THD)7
6L85629 STUD-TAPERLOCK (3/8-16X1.77-IN)4
2N276510 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)3
7E390411 TUBE1
8N087812 CLAMP2
1W048113 RING-EXHAUST SEAL2
106940814 SEAL-EXHAUST2
4N724815 PLATE1
4N184816 GASKET1
7W649217 PLUG-PIPE (1/2-14-THD)1
7N966918 PIPE-OUTLET1
4L833719 SEAL-O-RING2
5S118820 SEAL-O-RING2
9F859621 LUG2
1A202922 BOLT (3/8-16X1.125-IN)2
5M289423 WASHER-HARD (10.2X18.5X2.5-MM THK)10
0S159424 BOLT (3/8-16X1-IN)2
9N108125 ADAPTER-TRANSFER PIPE1
6N233126 GASKET1
5L885427 RING-SEALING2
8T676528 PLUG-PIPE (1/4-18-THD)3
4N101029 SUPPORT-ELBOW1
4N115730 COUPLING-EXHAUST1
7E390133 TUBE (EXHAUST)1
7E390234 TUBE1
7E390335 TUBE1
2A463936 BOLT (3/8-16X1.625-IN)2
8N087937 CLAMP4
2W079638 SUPPORT-EXHAUST PIPE1
