Assembly
100%

8N-3600 MANIFOLD GP-EXHAUSTS/N 78Z1144-1144; 78Z1180-1324

Group No: 8N-3600
Part NumberPart NameQty
3J53901 PLUG (3/8-18-THD)2
0T05732 BOLT (3/8-16X2.75-IN)8
1D47173 NUT (3/8-16-THD)18
5M28944 WASHER-HARD (10.2X18.5X2.5-MM THK)29
0L11435 BOLT (3/8-16X2.5-IN)1
0L20706 BOLT (3/8-16X2.25-IN)6
4N50737 ELBOW4
4N50388 PIPE2
5K59599 SEAL-O-RING4
7N317510 MANIFOLD AS1
0S159111 BOLT (3/8-16X1.5-IN)6
7N817512 GASKET-MANIFOLD8
0S159113 BOLT (3/8-16X1.5-IN)4
7L052014 STUD-TAPERLOCK (3/8-16X1.968-IN)4
8N384115 PLATE1
8N053816 MANIFOLD AS (RH)1
4N544417 MANIFOLD AS (LH)1
4N079018 GASKET8
6L856219 STUD-TAPERLOCK (3/8-16X1.77-IN)4
4N503720 ELBOW2
4N544721 ADAPTER2
5K595922 SEAL-O-RING4
4N507323 ELBOW2
2N2766LOCKNUT (3/8-16-THD)16
5M289424 WASHER-HARD (10.2X18.5X2.5-MM THK)16
6N9340SPACER (0.391X0.688X1.12-IN THK)16
4N191825 GASKET-WOUND2
