System And Components
6N-3249 TURBOCHARGER GPS/N 78Z1144-1995
Group No: 6N-3249
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N9538 | 1 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 4N9540 | HOUSING AS-CENTER | 1 | |
| 5S5199 | PIN-GROOVED | 2 | |
| 4M6983 | 2 RING-RETAINING | 4 | |
| 4N9556 | 3 SHROUD | 1 | |
| 4M6990 | 4 RING-SNAP | 1 | |
| 9S8993 | 5 WHEEL AS | 1 | |
| 7N2856 | 6 RING-SEAL | 1 | |
| 5S4551 | 7 SLEEVE-OIL CONTROL | 1 | |
| 8S9223 | 8 BEARING-THRUST | 1 | |
| 5S4547 | SLEEVE-SPACER | 1 | |
| 5S4550 | 9 RING-THRUST | 2 | |
| 5S4557 | 10 BEARING | 2 | |
| 8S9222 | 11 SLEEVE | 1 | |
| 7N0239 | 12 NUT-TURBOCHARGER COMPRESSOR | 1 | |
| 4M8013 | 13 RING-PISTON | 2 | |
| 5S4556 | 14 INSERT | 1 | |
| 9N2377 | 15 WHEEL-COMPRESSOR | 1 | |
| 5S4549 | 16 DEFLECTOR-OIL | 1 | |
| 5S4546 | 17 RING-RETAINING | 1 | |
| 5S4554 | 18 SEAL-O-RING | 1 | |
| 5P5757 | 19 SEAL-O-RING | 1 | |
| 5S4545 | 20 PLATE-IDENTIFICATION | 1 | |
| 8H3710 | 21 SCREW-TAPPING (6-32X0.375-IN) | 2 | |
| 5S4517 | 22 CLAMP AS (TURBINE) | 1 | |
| 7M9918 | LOCKNUT (1/4-28-THD) | 1 | |
| 4N6699 | 23 HOUSING | 1 | |
| 9N0671 | 24 COVER-COMPRESSOR | 1 | |
| 5S4558 | 25 CLAMP AS-COMPRESSOR | 1 | |
| 7M9918 | LOCKNUT (1/4-28-THD) | 1 | |
| 6N7245 | CARTRIDGE GP-TURBOCHARGER | 1 |
