System And Components
2W-5767 PUMP GP-GOV & FUEL INJS/N 63Z590-1532
Group No: 2W-5767
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1066 | 1 LEVER AS-PIVOT | 1 | |
| 8N4109 | LEVER AS | 1 | |
| 6V6835 | 2 SETSCREW-SOCKET (10-32X0.625-IN) | 1 | |
| 4B2049 | 3 NUT (10-32-THD) | 1 | |
| 6V6835 | 4 SETSCREW-SOCKET (10-32X0.625-IN) | 1 | |
| 4B2049 | 5 NUT (10-32-THD) | 1 | |
| 2D6392 | 6 SEAL-O-RING | 1 | |
| 6M5062 | 7 SEAL-O-RING | 1 | |
| 8N5403 | 8 SHAFT AS-THROTTLE | 1 | |
| 6N1716 | 9 VALVE AS | 1 | |
| 2W2411 | 10 PUMP GP-GOV & FUEL INJ | 1 | |
| 7N2176 | 11 PIN-DETENT | 1 | |
| 8N3096 | 12 SPRING-DETENT | 1 | |
| 7N1052 | 13 DOWEL | 1 | |
| 2W1861 | 14 TORQUE CONTROL GP | 1 | |
| 8M9141 | 15 SPRING | 1 | |
| 2W5448 | 16 COVER | 1 | |
| 2W5447 | GASKET | 1 | |
| 0S1615 | 17 BOLT (1/4-20X0.75-IN)(1/4-20X.75IN) | 2 | |
| 5D6539 | 18 SEAL-O-RING | 1 | |
| 5L4758 | 19 SEAL-O-RING | 1 | |
| 7N5334 | 20 SETSCREW-SOCKET (25.4-MM LG) | 1 | |
| 4B2049 | NUT (10-32-THD) | 1 |
