1W-9801 CYLINDER HEAD GPS/N 99U4604-4737

Group No: 1W-9801
Part NumberPart NameQty
9N25831 BRACKET-FUEL PUMP1
0S15912 BOLT (3/8-16X1.5-IN)1
5M28943 WASHER-HARD (10.2X18.5X2.5-MM THK)2
8S91914 BOLT (3/8-16X4-IN)1
1A51835 BOLT (3/8-16X4.75-IN)1
5B26386 BOLT (3/8-16X5.25-IN)1
6N67317 SUPPORT-HOUSING (LH)1
2W79848 GASKET-CYLINDER HEAD2
2H37509 BOLT (3/4-16X7.5-IN)28
5H150410 WASHER-HARD (20X33.5X5-MM THK)28
1W980211 CYLINDER HEAD GP2
0L135212 BOLT (3/8-16X3.25-IN)11
4N093213 PLUG-CUP (57.53-MM OD)2
5P006314 PLUG-CUP4
3J539015 PLUG (3/8-18-THD)2
4W105516 SEAL32
4S613717 STUD-TAPERLOCK (3/8-16X3.1-IN)16
1B517418 PLUG-PIPE2
2B085819 PLUG-PIPE2
3J538920 PLUG (EXTERNAL)2
5M621421 PLUG (1/8-27 PTF)2
6N673222 SUPPORT-HOUSING (RH)1
5B263823 BOLT (3/8-16X5.25-IN)1
1A518324 BOLT (3/8-16X4.75-IN)1
5M289425 WASHER-HARD (10.2X18.5X2.5-MM THK)3
0S159126 BOLT (3/8-16X1.5-IN)1
8S919127 BOLT (3/8-16X4-IN)2
1W520728 BRACKET-FUEL PUMP1
2S225129 SEAL-O-RING8
4W573330 ADAPTER AS-VALVE8
1W889531 GASKET8
