System And Components
4N-8505 DRIVE GP-AUXILIARYRH REAR - 3 GROOVE PULLEY
Group No: 4N-8505
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2K4821 | 1 LOCKNUT (5/8-18-THD) | 1 | |
| 4D3704 | WASHER-HARD (17X30X5-MM THK) | 1 | |
| 4N8787 | 2 GEAR-AUXILIARY DRIVE (46 TEETH) | 1 | |
| 5P8940 | 3 SEAL-O-RING | 1 | |
| 4N8788 | 4 HOUSING-AUXILIARY DRIVE | 1 | |
| 2D5658 | 5 BALL BEARING | 1 | |
| 2H3777 | 6 LOCKNUT (1-5/8-18-THD) | 1 | |
| 1K6985 | 7 RING-RETAINING | 1 | |
| 1B4117 | 8 BALL BEARING | 1 | |
| 3J0365 | 9 SEAL-LIP TYPE | 1 | |
| 4N8462 | 10 PULLEY-AUXILIARY DRIVE (3-GROOVE) | 1 | |
| 2M1538 | 11 STUD-TAPERLOCK (3/8-16X1.6-IN) | 5 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 5 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 2W7917 | 12 SHAFT-AUXILIARY DRIVE | 1 | |
| 0L1352 | 13 BOLT (3/8-16X3.25-IN) | 2 | |
| 8J8322 | 14 RING-RETAINING | 1 | |
| 5F8916 | 15 LOCKWASHER | 1 |
