System And Components
9N-1076 BELT TIGHTENER GPFOR USAGE REFER TO CHART 9N-1294
Group No: 9N-1076
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1587 | 1 BOLT (1/2-13X1.75-IN) | 1 | |
| 9N3383 | 2 COVER | 1 | |
| 7W5648 | 3 GASKET | 1 | |
| 1A2029 | 4 BOLT (3/8-16X1.125-IN) | 4 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8S9092 | 5 BOLT (5/8-11X2.25-IN) | 1 | |
| 4D3704 | WASHER-HARD (17X30X5-MM THK) | 1 | |
| 0L0695 | 6 WASHER (16.7X47.6X6-MM THK) | 1 | |
| 9N3228 | 7 BRACKET-PULLEY | 1 | |
| 3B8489 | 8 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 7H7954 | 9 BOLT (3/8-16X2.125-IN) | 2 | |
| 2F6262 | WASHER | 1 | |
| 9F2247 | 10 PLUG-PIPE (1/8-27-THD) | 1 | |
| 1W6134 | 11 COVER | 1 | |
| 9N0319 | 12 PULLEY-TIGHTENER | 1 | |
| 8H9789 | 13 BALL BEARING | 2 | |
| 9N0311 | 14 SPACER-BEARING | 1 | |
| 5S2106 | 15 SEAL-LIP TYPE | 1 | |
| 9N1012 | 16 SPACER-BEARING (1.438X1.75X1-IN THK) | 1 | |
| 7F2122 | 17 SEAL-O-RING | 1 | |
| 9L6329 | 18 BLOCK | 1 | |
| 1B4430 | 19 NUT-JAM (1/2-20-THD) | 2 | |
| 1A1460 | 20 BOLT (1/2-13X2-IN) | 1 | |
| 2M0849 | 21 WASHER-HARD (13.5X25.5X5-MM THK) | 3 | |
| 0S1585 | 22 BOLT (1/2-13X1.5-IN) | 1 | |
| 9N3229 | 23 BRACKET | 1 | |
| 4N4942 | 24 ROD-ADJUSTMENT | 1 | |
| 5P8831 | 25 STUD-TAPERLOCK (3/8-16X4.75-IN) | 2 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 2 | |
| 0S1588 | 26 BOLT (3/8-16X1.25-IN) | 1 |
