System And Components
9N-2803 DRIVE GP-FANFOR USAGE REFER TO CHART 9N-1294
Group No: 9N-2803
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8487 | 1 FITTING-GREASE | 1 | |
| 5K9239 | 2 CONNECTOR | 1 | |
| 9N1013 | 3 PULLEY-FAN DRIVE | 1 | |
| 3B1915 | 4 BOLT (3/8-16X1.375-IN) | 6 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 7F2122 | 5 SEAL-O-RING | 1 | |
| 1H5403 | 6 BOLT (5/16-24X2-IN) | 2 | |
| 5S7264 | WASHER-RETAINING (0.219-IN THK) | 1 | |
| 8H9789 | 7 BALL BEARING | 2 | |
| 9N1017 | 8 SPACER-BEARING | 1 | |
| 5M1932 | 9 STUD-TAPERLOCK (1/2-13X2.17-IN) | 4 | |
| 1D4719 | NUT-FULL (1/2-13-THD) | 4 | |
| 2M0849 | WASHER-HARD (13.5X25.5X5-MM THK) | 4 | |
| 9N2801 | 10 BRACKET AS-FAN | 1 | |
| 9N1258 | BRACKET AS-FAN | 1 | |
| 9N1274 | 11 SHAFT-FAN | 1 | |
| 5B5812 | 12 DOWEL | 1 | |
| 9S7720 | 13 ELBOW-FLARED | 1 | |
| 5S9062 | 14 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 5S2106 | 15 SEAL-LIP TYPE | 1 | |
| 9N3378 | 16 TUBE AS-SUPPLY | 1 |
