System And Components
1S-3998 VALVE AS-RETARDERPART OF 9N-1821 CONTROL GP-BRAKESAVER
Group No: 1S-3998
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D5239 | 1 BOLT-12 POINT HEAD (3/8-16X1.625-IN) | 2 | |
| 4D5263 | 2 VALVE AS (OPERATOR CONTROL) | 1 | |
| 4D5262 | 3 SPRING-RETURN | 1 | |
| 3H1461 | 4 SEAL-O-RING | 1 | |
| 4D5246 | 5 PISTON | 1 | |
| 4D5248 | 6 GASKET | 1 | |
| 4D5245 | 7 COVER AS | 1 | |
| 1S3999 | 8 SPRING | 1 | |
| 7D2117 | 9 CAM & FOLLOWER AS | 1 | |
| 4D5256 | 10 SEAL-O-RING | 1 | |
| 4D5252 | 11 NUT-ADJUSTMENT | 1 | |
| 4D5254 | 12 RING-LOCKWASHER | 1 | |
| 1S3420 | 13 KNOB (WHITE, OPERATOR CONTROL) | 1 | |
| 4D7066 | 14 HANDLE AS | 1 | |
| 4D5253 | 15 SETSCREW (5/16-18-THD) | 1 | |
| 4B1328 | 16 SCREW-MACHINE (5/16-18X0.625-IN) | 2 | |
| 4D5238 | 17 CLAMP | 1 | |
| 4B1319 | 18 SCREW-MACHINE (1/4-20X0.5-IN) | 2 | |
| 4M8303 | 19 SEAL-O-RING | 1 | |
| 4D5243 | 20 LOCKWASHER | 2 | |
| 3B4504 | 21 LOCKWASHER | 2 |
