System And Components
9Y-7116 VALVE GP-BRAKESAVER CONTROLS/N 28V4777-UP
Group No: 9Y-7116
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 4 | |
| 5S4498 | 2 SLUG | 1 | |
| 6P4638 | 3 SPOOL | 1 | |
| 2S6547 | 4 STOP | 1 | |
| 9N6223 | 5 BODY-CONTROL VALVE | 1 | |
| 7W6492 | 6 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8T6765 | 7 PLUG-PIPE (1/4-18-THD) | 7 | |
| 7C0725 | 8 COVER | 1 | |
| 5R0419 | 9 BOLT-12 POINT HEAD (5/16-18X1.375-IN) | 1 | |
| 6P8601 | 10 STOP-RETARDER VALVE | 1 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 4 | |
| 9Y4811 | 12 DIAPHRAGM | 1 | |
| 2S6538 | 13 SPRING | 1 | |
| 6B5262 | 14 PLUG | 1 | |
| 1S5567 | 15 COVER | 1 | |
| 1S5646 | 16 SPRING | 1 | |
| 0336031 | 17 SEAL-O-RING | 1 | |
| 8L6565 | 18 PIN-SPRING | 1 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T6764 | 20 PLUG-PIPE (1/8-27-THD) | 2 | |
| 2A3398 | 21 GASKET | 1 |
