System And Components
9L-6415 LINES GP-ENGINE OILS/N 28V4913-5105
Group No: 9L-6415
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L1351 | 1 BOLT (3/8-16X0.875-IN) | 1 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 8M9024 | 3 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 0S1587 | 4 BOLT (1/2-13X1.75-IN) | 4 | |
| 2M0849 | WASHER-HARD (13.5X25.5X5-MM THK) | 4 | |
| 9L6904 | 5 CONNECTOR | 1 | |
| 0S1588 | 6 BOLT (3/8-16X1.25-IN) | 2 | |
| 1232894 | 7 SUPPORT-SUCTION LINE | 1 | |
| 5H5138 | 8 CLIP | 1 | |
| 0S1590 | 9 BOLT (3/8-16X2-IN) | 1 | |
| 0S1595 | 10 BOLT (1/2-13X1.25-IN) | 2 | |
| 1P3707 | 11 SEAL-RECTANGULAR | 1 | |
| 1A5822 | 12 BOLT (1/2-13X2.75-IN) | 2 | |
| 9S8752 | 13 NUT-FULL (3/8-16-THD) | 1 | |
| 8M7145 | 14 WASHER (10.2X28.5X5-MM THK) | 1 | |
| 9L6703 | 15 BRACKET | 1 | |
| 0S1594 | 16 BOLT (3/8-16X1-IN) | 2 | |
| 9N5919 | 17 TUBE AS | 1 | |
| 9N5103 | 18 BELL AS-SUCTION | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 2 | |
| 4N0913 | 19 SCREEN-STRAINER | 1 | |
| 4N0914 | 20 CLIP | 1 | |
| 2S6160 | 21 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 1090072 | 22 SEAL-O-RING | 3 | |
| 1W2641 | 23 TUBE-OIL | 2 | |
| 1090076 | SEAL-O-RING | 4 | |
| 0S1571 | 24 BOLT (3/8-16X1.75-IN) | 1 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P8068 | 26 SEAL-O-RING | 1 | |
| 0619455 | 27 SEAL-O-RING | 1 | |
| 9L6842 | 28 TUBE AS | 1 | |
| 0L2070 | 29 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1591 | 30 BOLT (3/8-16X1.5-IN) | 4 | |
| 9N5917 | 31 TUBE AS-PUMP SUCTION | 1 | |
| 5P5846 | 32 SEAL-O-RING | 1 | |
| 1090078 | 33 SEAL-O-RING | 4 | |
| 9L6731 | 34 TUBE AS-SUCTION | 1 | |
| 1031250 | 35 TUBE AS-PUMP | 1 | |
| 6V3830 | 36 SEAL-O-RING | 1 | |
| 9N2341 | 37 TUBE AS | 1 | |
| 1A2029 | 38 BOLT (3/8-16X1.125-IN) | 3 | |
| 2P3761 | 39 COVER | 1 | |
| 3K7346 | 40 SPRING | 1 | |
| 9M0853 | 41 PLUNGER-VALVE | 1 | |
| 1031249 | 42 BRACKET AS-VALVE | 1 | |
| 0347035 | SPACER (0.438X1.0X0.188-IN THK) | 1 | |
| 1P4579 | 43 FLANGE-HALF | 1 | |
| 5J7303 | 44 ELBOW | 1 | |
| 9N5978 | 45 HOSE AS (76CM) | 1 | |
| 8T6763 | 46 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9N0321 | 47 ELBOW-DRAIN | 2 | |
| 1142687 | 48 SEAL-O-RING | 3 | |
| 9L6910 | 49 GASKET | 2 | |
| 3B1915 | 50 BOLT (3/8-16X1.375-IN) | 8 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 0L1351 | 51 BOLT (3/8-16X0.875-IN) | 3 | |
| 9M6527 | WASHER-HARD (10.2X25.5X5-MM THK) | 3 | |
| 9N1270 | 52 TUBE-DRAIN | 1 | |
| 5B9603 | 53 BOLT (3/8-16X5-IN) | 2 | |
| 0S1588 | 54 BOLT (3/8-16X1.25-IN) | 4 | |
| 9N5679 | 55 MANIFOLD-BRAKESAVER | 1 | |
| 9N2048 | 56 TUBE AS | 1 | |
| 9S7296 | 57 ELBOW-FLARED | 1 | |
| 0016449 | 58 CONNECTOR | 1 | |
| 9N0643 | 59 SLEEVE | 2 | |
| 9X7432 | 60 SEAL-O-RING | 2 | |
| 0619457 | 61 SEAL-O-RING | 2 | |
| 9L6906 | 62 ELBOW | 1 | |
| 5P9085 | 63 CLIP (LOOP) | 1 | |
| 1S9593 | 64 STRAP-CABLE | 1 |
