System And Components
1N-3636 LINES GP-AIRTURBOCHARGER AFTERCOOLER
Group No: 1N-3636
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9M4225 | 1 BOLT (3/8 NCX4 3/8) | 2 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 4N6296 | 3 GASKET | 1 | |
| 9L5995 | 4 ELBOW | 1 | |
| 0S1608 | 5 BOLT (3/8-16X3.75-IN) | 1 | |
| 0S1588 | 6 BOLT (3/8-16X1.25-IN) | 3 | |
| 9L5994 | 7 PIPE-AIR TRANSFER | 1 | |
| 4L8337 | 8 SEAL-O-RING | 4 | |
| 1092332 | 9 SEAL-O-RING | 1 | |
| 9N6472 | 10 SUPPORT-MANIFOLD | 1 | |
| 7E3904 | 11 TUBE | 1 | |
| 7E3903 | 12 TUBE | 1 | |
| 5L8854 | 13 RING-SEALING | 2 | |
| 9L5839 | 14 COUPLING-EXHAUST | 1 | |
| 9N1865 | 15 SUPPORT-EXHAUST PIPE | 1 | |
| 2N2765 | 16 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 2 | |
| 2N2766 | 17 LOCKNUT (3/8-16-THD) | 6 | |
| 9N5421 | 18 MANIFOLD | 1 | |
| 5B7890 | 19 PLUG-PIPE | 2 | |
| 8N0878 | 20 CLAMP | 2 | |
| 1069408 | SEAL-EXHAUST | 2 | |
| 7E3901 | 22 TUBE (EXHAUST) | 1 | |
| 7E3905 | 23 TUBE-EXHAUST | 1 | |
| 0S1591 | 24 BOLT (3/8-16X1.5-IN) | 1 | |
| 2W0794 | 25 SUPPORT-EXHAUST PIPE | 1 | |
| 6L8562 | 26 STUD-TAPERLOCK (3/8-16X1.77-IN) | 4 | |
| 0S1571 | 27 BOLT (3/8-16X1.75-IN) | 4 | |
| 1W0481 | 28 RING-EXHAUST SEAL | 2 | |
| 0T0065 | 29 BOLT (3/8-16X3.5-IN) | 1 | |
| 8N0879 | 30 CLAMP | 4 |
