System And Components
7N-2850 AIR COMPRESSOR GP12 CFM BELT DRIVEN. MOUNTS ON LH FRONT
Group No: 7N-2850
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B4618 | 1 PIN-COTTER | 1 | |
| 6N8643 | 2 PULLEY-AIR COMPRESSOR (1-GROOVE) | 1 | |
| 6N3611 | 3 AIR COMPRESSOR GP | 1 | |
| 6N3135 | 4 SUMP-COMPRESSOR | 1 | |
| 6B7254 | 5 STUD-TAPERLOCK | 3 | |
| 0L0765 | 6 STUD (3/8-16X1.75-IN) | 2 | |
| 6N3399 | 7 BRACKET AS | 1 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 6 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 9L4238 | 10 BOLT (3/8-16X8.5-IN) | 1 | |
| 6N0634 | 11 GASKET-COVER | 1 | |
| 1D4703 | 12 BOLT (7/16-14X2.5-IN) | 4 | |
| 1D4718 | NUT-FULL (7/16-14-THD) | 4 | |
| 4S9191 | WASHER (12X22.5X5-MM THK) | 8 | |
| 6N7721 | 13 V-BELT (AIR COMPRESSOR) | 1 | |
| 1D4717 | 14 NUT (3/8-16-THD) | 3 | |
| 5B4274 | 15 BOLT (3/8-16X3.5-IN) | 1 | |
| 1B7182 | 16 BOLT (5/16-18X1.25-IN) | 3 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 3B1915 | 17 BOLT (3/8-16X1.375-IN) | 1 | |
| 0S1608 | 18 BOLT (3/8-16X3.75-IN) | 2 | |
| 6N7705 | 19 ADAPTER | 1 | |
| 1S1225 | SEAL-O-RING | 1 |
