System And Components
1W-8856 CLUTCH GPPART OF 1W-8857 POWER TAKE-OFF GP
Group No: 1W-8856
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1L7796 | 1 KEY | 1 | |
| 1L5015 | 2 PLATE-CLUTCH | 1 | |
| 4L3527 | 3 PLATE-CLUTCH DRIVING | 3 | |
| 3N8125 | 4 PLATE AS-PRESSURE | 1 | |
| 3N8124 | SPRING | 1 | |
| 3N8123 | LOCK PIN | 1 | |
| 3F3728 | 5 RING-SNAP | 1 | |
| 1L4863 | 6 WASHER-SPRING | 8 | |
| 6L3972 | 7 PIN | 4 | |
| 4H0002 | 8 LEVER | 4 | |
| 6L3961 | 9 PIN-COTTER | 4 | |
| 4B4721 | 10 LINK | 8 | |
| 6L3967 | 11 PIN | 8 | |
| 6L3964 | 12 PIN-COTTER | 8 | |
| 5B2410 | 13 HOSE AS | 1 | |
| 4B4716 | 14 COLLAR AS-SLEEVE | 1 | |
| 0L0639 | BOLT (3/8-24X2.25-IN) | 2 | |
| 2L6267 | LOCKNUT (3/8-24-THD) | 2 | |
| 4B4758 | SHIM (0.06-IN THK) | 2 | |
| 6B3223 | 15 CUP-BEARING | 2 | |
| 4B7270 | 16 CONE-BEARING | 2 | |
| 4B4764 | 17 NUT | 1 | |
| 4B4773 | 18 LOCK | 1 | |
| 5L3486 | 19 RING-DRIVE | 1 | |
| 3H9571 | 20 PLATE-CENTER | 2 | |
| 3H9572 | 21 RING-ADJUSTMENT | 1 | |
| 3H9574 | 22 SLEEVE (SLIDING) | 1 | |
| 4B4792 | 23 YOKE AS | 1 | |
| 0S1591 | BOLT (3/8-16X1.5-IN) | 2 | |
| 3B4506 | LOCKWASHER | 2 | |
| 6L5151 | 24 KEY-WOODRUFF | 2 | |
| 3L0648 | 25 SHAFT-OPERATING | 1 | |
| 5B2404 | 26 RETAINER-BEARING | 1 | |
| 5B2407 | 27 LOCK | 1 | |
| 0S1617 | 28 BOLT (5/16-18X0.75-IN) | 1 | |
| 3F9556 | LOCKWASHER | 1 | |
| 3B8489 | 29 FITTING-GREASE (1/8-27 PTF)(CLUTCH) | 2 | |
| 6F0253 | 30 LOCKWASHER | 1 | |
| 9S1354 | 31 NUT (5/8-18-THD) | 1 | |
| 0S1587 | 32 BOLT (1/2-13X1.75-IN) | 2 | |
| 1L6931 | 33 SCREW AS-MACHINE (1/4-20X0.5-IN) | 2 | |
| 8B7121 | 34 FITTING-HYDRAULIC (CLUTCH) | 2 | |
| 1A1460 | 35 BOLT (1/2-13X2-IN) | 4 | |
| 3B4508 | 36 LOCKWASHER | 6 | |
| 5B2406 | 37 CARRIER | 1 | |
| 5N1932 | 38 SHAFT-CLUTCH | 1 | |
| 1L5014 | 39 HOUSING-CLUTCH | 1 | |
| 4B4810 | 40 LEVER AS-HAND | 1 | |
| 0S1587 | 41 BOLT (1/2-13X1.75-IN) | 1 | |
| 1083561 | 42 PLATE-INSTRUCTION (POWER TAKE-OFF) | 1 |
