System And Components
2W-4910 CLUTCH GPPART OF 2W-4911 POWER TAKE-OFF GP
Group No: 2W-4910
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF)(CLUTCH) | 2 | |
| 6F0253 | 2 LOCKWASHER | 1 | |
| 9S1354 | 3 NUT (5/8-18-THD) | 1 | |
| 0S1587 | 4 BOLT (1/2-13X1.75-IN) | 2 | |
| 1L6931 | 5 SCREW AS-MACHINE (1/4-20X0.5-IN) | 2 | |
| 8B7121 | 6 FITTING-HYDRAULIC | 2 | |
| 1A1460 | 7 BOLT (1/2-13X2-IN) | 4 | |
| 3B4508 | 8 LOCKWASHER | 6 | |
| 5B2406 | 9 CARRIER | 1 | |
| 5N1932 | 10 SHAFT-CLUTCH | 1 | |
| 4L3528 | 11 HOUSING-CLUTCH | 1 | |
| 4W2653 | 12 LEVER AS-HAND | 1 | |
| 0S1587 | BOLT (1/2-13X1.75-IN) | 1 | |
| 5B2410 | 13 HOSE AS | 1 | |
| 2W7883 | 14 PLATE-INSTRUCTION | 1 | |
| 1L7796 | 15 KEY | 1 | |
| 1L5015 | 16 PLATE-CLUTCH | 1 | |
| 4L3527 | 17 PLATE-CLUTCH DRIVING | 3 | |
| 3N8125 | 18 PLATE AS-PRESSURE | 1 | |
| 3N8124 | SPRING | 1 | |
| 3N8123 | LOCK PIN | 1 | |
| 1L4863 | 19 WASHER-SPRING | 8 | |
| 6L3972 | 20 PIN | 4 | |
| 4H0002 | 21 LEVER | 4 | |
| 6L3961 | 22 PIN-COTTER | 4 | |
| 4B4721 | 23 LINK | 8 | |
| 6L3967 | 24 PIN | 8 | |
| 6L3964 | 25 PIN-COTTER | 8 | |
| 4B4716 | 26 COLLAR AS-SLEEVE | 1 | |
| 0L0639 | 27 BOLT (3/8-24X2.25-IN) | 2 | |
| 2L6267 | LOCKNUT (3/8-24-THD) | 2 | |
| 4B4758 | SHIM (0.06-IN THK) | 2 | |
| 6B3223 | 28 CUP-BEARING | 2 | |
| 4B7270 | 29 CONE-BEARING | 2 | |
| 4B4764 | 30 NUT | 1 | |
| 4B4773 | 31 LOCK | 1 | |
| 5L3486 | 32 RING-DRIVE | 1 | |
| 3H9571 | 33 PLATE-CENTER | 2 | |
| 3H9572 | 34 RING-ADJUSTMENT | 1 | |
| 3H9574 | 35 SLEEVE | 1 | |
| 4B4792 | 36 YOKE AS | 1 | |
| 0S1591 | 37 BOLT (3/8-16X1.5-IN) | 2 | |
| 3B4506 | LOCKWASHER | 2 | |
| 6L5151 | 38 KEY-WOODRUFF | 2 | |
| 4B4770 | 39 SHAFT | 1 | |
| 5B2404 | 40 RETAINER-BEARING | 1 | |
| 5B2407 | 41 LOCK | 1 | |
| 0S1617 | 42 BOLT (5/16-18X0.75-IN) | 1 | |
| 3F9556 | 43 LOCKWASHER | 1 | |
| 3F3728 | 44 RING-SNAP | 1 |
