System And Components
2W-4914 CLUTCH GPPART OF 2W-4915, 7W-7532 POWER TAKE-OFF GP
Group No: 2W-4914
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N6136 | 1 PLATE-DRIVE | 3 | |
| 8L5188 | 2 PIN | 4 | |
| 6L3963 | PIN-COTTER | 4 | |
| 8L8457 | 3 YOKE-ADJUSTMENT | 1 | |
| 8L5107 | 4 LEVER | 4 | |
| 8L5200 | 5 PIN | 4 | |
| 6L3962 | 6 PIN-COTTER | 8 | |
| 8L5095 | 7 LINK-LEVER | 8 | |
| 8L5199 | 8 PIN | 4 | |
| 8L5094 | 9 RING-COLLAR | 1 | |
| 1B8702 | KEY-WOODRUFF | 1 | |
| 8L5679 | 10 RING-RETAINING | 1 | |
| 2H3755 | 11 BOLT (5/16-18X0.43-IN) | 1 | |
| 5B2407 | LOCK | 1 | |
| 8L5099 | 12 RETAINER-BEARING | 1 | |
| 2W4905 | 13 RING-SEAL | 2 | |
| 4L6105 | 14 PLATE-DRIVE | 3 | |
| 4F7499 | 15 CONE-BEARING | 2 | |
| 5D7449 | 16 CUP-BEARING | 2 | |
| 8L5189 | 17 SEAL-O-RING | 1 | |
| 1B8737 | 18 KEY-WOODRUFF | 2 | |
| 1D4539 | 19 BOLT (5/16-18X2.5-IN) | 1 | |
| 2W7876 | 20 FORK-THROW-OUT | 1 | |
| 8L5105 | 21 COLLAR AS-SLEEVE | 1 | |
| 0V0375 | BOLT (1/2-13X3.25-IN) | 2 | |
| 2K0564 | LOCKNUT (1/2-20-THD) | 2 | |
| 8L5186 | SHIM (0.06-IN THK)(0.06IN THK) | 2 | |
| 8L8458 | 22 SLEEVE-SLIDING | 1 | |
| 3N1462 | 23 PIN AS | 1 | |
| 8L8459 | 24 PLATE-PRESSURE | 1 | |
| 8L8462 | 25 PLATE AS-CENTER | 2 | |
| 8L8460 | 26 RING-DRIVE | 1 | |
| 8L8464 | 27 HUB & BACKPLATE | 1 | |
| 8L5198 | 28 LOCKWASHER | 1 | |
| 8L5185 | 29 KEY | 1 | |
| 8L5184 | 30 NUT-SHAFT | 1 | |
| 4W2655 | 31 LEVER-HAND CONTROL | 1 | |
| 3N9627 | 32 SHAFT-CLUTCH | 1 | |
| 1H2415 | 33 BOLT (0.5-13X2.5-IN) | 1 | |
| 1D4719 | NUT-FULL (1/2-13-THD) | 1 | |
| 8B7121 | 34 FITTING-HYDRAULIC | 2 | |
| 2B0858 | 35 PLUG-PIPE | 2 | |
| 7H3171 | 36 PLUG-PIPE | 1 | |
| 8L5101 | 37 SHAFT | 1 | |
| 2W7879 | 38 HOUSING-CLUTCH | 1 | |
| 2W7878 | 39 CARRIER AS-BEARING | 1 | |
| 0S1625 | 40 BOLT (5/8-11X2.5-IN) | 8 | |
| 9B2515 | 41 FITTING-HYDRAULIC (CLUTCH) | 1 | |
| 3B8489 | 42 FITTING-GREASE (1/8-27 PTF)(CLUTCH) | 1 | |
| 9S1354 | 43 NUT (5/8-18-THD) | 1 | |
| 6F0253 | LOCKWASHER | 1 | |
| 8L5096 | 44 HOSE AS (41.91CM) | 1 | |
| 4M5317 | 45 BUSHING-REDUCER (REDUCING) | 1 | |
| 7L2227 | 46 BREATHER (CLUTCH HOUSING) | 1 | |
| 1C0569 | 47 BOLT (5/16-18X0.5-IN) | 2 |
