System And Components
4P-3068 CLUTCH GPPART OF 112-1718, 4P-3069 POWER TAKE-OFF GP
Group No: 4P-3068
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L8460 | 1 RING-DRIVE | 1 | |
| 7C8373 | 2 SHAFT-STUB | 1 | |
| 8L5159 | 3 BALL BEARING | 1 | |
| 1A8063 | 4 BOLT (3/4-10X2.5-IN) | 1 | |
| 7C3872 | 5 WASHER-RETAINING | 1 | |
| 7C3871 | 6 SHIM-RETAINER (0.13-MM THK) | 1 | |
| 7C3877 | SHIM-RETAINER (0.18-MM THK) | 1 | |
| 7C3878 | SHIM-RETAINER (0.51-MM THK) | 1 | |
| 7W7535 | 7 HUB | 1 | |
| 5N6136 | 8 PLATE-DRIVE | 3 | |
| 8L8462 | 9 PLATE AS-CENTER | 2 | |
| 8L8459 | 10 PLATE-PRESSURE | 1 | |
| 6L3963 | 11 PIN-COTTER | 4 | |
| 8L5107 | 12 LEVER | 4 | |
| 8L5188 | 13 PIN | 4 | |
| 8L8457 | 14 YOKE-ADJUSTMENT | 1 | |
| 6L3962 | 15 PIN-COTTER | 8 | |
| 8L5095 | 16 LINK-LEVER | 8 | |
| 8L5200 | 17 PIN | 4 | |
| 8L5199 | 18 PIN | 4 | |
| 8L8458 | 19 SLEEVE-SLIDING | 1 | |
| 8L5105 | 20 COLLAR AS-SLEEVE | 1 | |
| 2K0564 | 21 LOCKNUT (1/2-20-THD) | 2 | |
| 8L5186 | 22 SHIM (0.06-IN THK) | 2 | |
| 0V0375 | 23 BOLT (1/2-13X3.25-IN) | 2 | |
| 3B8489 | 24 FITTING-GREASE (1/8-27 PTF)(CLUTCH) | 2 | |
| 9S1354 | 25 NUT (5/8-18-THD) | 1 | |
| 6F0253 | 26 LOCKWASHER | 1 | |
| 4M5317 | 27 BUSHING-REDUCER | 1 | |
| 8L5096 | 28 HOSE AS | 1 | |
| 8B7121 | 29 FITTING-HYDRAULIC (CLUTCH) | 2 | |
| 2W7879 | 30 HOUSING-CLUTCH | 1 | |
| 8L5094 | 31 RING-COLLAR | 1 | |
| 1C0569 | 32 BOLT (5/16-18X0.5-IN) | 2 | |
| 8L5679 | 33 RING-RETAINING | 1 | |
| 3N1462 | 34 PIN AS | 1 | |
| 3N1461 | 35 SPRING | 1 | |
| 2H3755 | 36 BOLT (5/16-18X0.43-IN) | 1 | |
| 5B2407 | 37 LOCK | 1 | |
| 8L5099 | 38 RETAINER-BEARING | 1 | |
| 1B8702 | 39 KEY-WOODRUFF | 1 | |
| 6V8234 | 40 PIN-SPRING | 1 | |
| 5D7449 | 41 CUP-BEARING | 2 | |
| 6B8575 | 42 KEY-SQUARE | 1 | |
| 7W7534 | 43 SHAFT | 1 | |
| 9Y4298 | 44 PLATE-INSTRUCTION (POWER TAKE-OFF) | 1 | |
| 4F7499 | 45 CONE-BEARING | 2 | |
| 4B9782 | 46 BALL | 1 | |
| 2W7878 | 47 CARRIER AS-BEARING | 1 | |
| 0S1625 | 48 BOLT (5/8-11X2.5-IN) | 8 | |
| 2W4905 | 49 RING-SEAL | 2 | |
| 2B0858 | 50 PLUG-PIPE | 2 | |
| 7H3171 | 51 PLUG-PIPE | 1 | |
| 4W2655 | 52 LEVER-HAND CONTROL | 1 | |
| 2W7876 | 53 FORK-THROW-OUT | 1 | |
| 1D4539 | 54 BOLT (5/16-18X2.5-IN) | 1 | |
| 8L5101 | 55 SHAFT | 1 | |
| 1B8737 | 56 KEY-WOODRUFF | 2 |
