System And Components
7N-8845 DRIVE GP-FAN -BLOWERFOR USAGE REFER TO CHART 4N-6973
Group No: 7N-8845
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9L0553 | 1 STUD-TAPERLOCK (1/2-13X4.25-IN) | 4 | |
| 1F7960 | WASHER (13.5X32X6-MM THK) | 4 | |
| 6N2547 | 2 ADAPTER-FAN BRACKET | 1 | |
| 5S9062 | 3 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 5S2106 | 4 SEAL-LIP TYPE | 1 | |
| 7N8827 | 5 HUB | 1 | |
| 0L2070 | 6 BOLT (3/8-16X2.25-IN) | 6 | |
| 6N6798 | 7 V-BELT SET (INCLUDES 3-BELTS)(FAN DRIVE) | 1 | |
| 4N6289 | 8 PULLEY-FAN DRIVE (3-GROOVE)(3-GROOVE) | 1 | |
| 3L1425 | 9 BALL BEARING | 1 | |
| 2D4867 | 10 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 1B5174 | 11 PLUG-PIPE | 1 | |
| 6N6598 | 12 ADAPTER-FAN | 1 | |
| 1H5403 | 13 BOLT (5/16-24X2-IN) | 2 | |
| 5S7264 | WASHER-RETAINING (0.219-IN THK) | 1 | |
| 5P7979 | BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 7N2900 | RETAINER | 1 | |
| 9F4446 | 14 SEAL-O-RING | 1 | |
| 8N5305 | 15 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 8H9789 | 16 BALL BEARING | 1 | |
| 6N7688 | 17 BRACKET AS-FAN | 1 | |
| 1P9946 | 17A SHAFT-FAN | 1 | |
| 4N0684 | 17B DOWEL | 1 | |
| 4B4550 | 18 FITTING-PRESSURE RELIEF (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 8L5213 | 19 BOLT (3/8-16X4-IN) | 1 | |
| 6V8801 | NUT (3/8-16-THD) | 1 | |
| 0S1594 | 20 BOLT (3/8-16X1-IN) | 2 | |
| 6N2538 | 21 BRACKET-FAN ADJUSTMENT | 1 | |
| 1D4719 | 22 NUT-FULL (1/2-13-THD) | 4 |
