System And Components
7N-8847 DRIVE GP-FAN -BLOWERFOR USAGE REFER TO CHART 4N-6973
Group No: 7N-8847
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N8827 | 1 HUB | 1 | |
| 5S2106 | 2 SEAL-LIP TYPE | 1 | |
| 5S9062 | 3 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 8L5213 | 4 BOLT (3/8-16X4-IN) | 1 | |
| 9S8752 | 5 NUT-FULL (3/8-16-THD) | 1 | |
| 6N2538 | 6 BRACKET-FAN ADJUSTMENT | 1 | |
| 0S1594 | 7 BOLT (3/8-16X1-IN) | 2 | |
| 6N2547 | 8 ADAPTER-FAN BRACKET | 1 | |
| 6N7688 | 9 BRACKET AS-FAN | 1 | |
| 1P9946 | 9A SHAFT-FAN | 1 | |
| 4N0684 | 9B DOWEL | 1 | |
| 1F7960 | 10 WASHER (13.5X32X6-MM THK) | 4 | |
| 9L0553 | 11 STUD-TAPERLOCK (1/2-13X4.25-IN) | 4 | |
| 8N5305 | 12 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 8H9789 | 13 BALL BEARING | 1 | |
| 6N9158 | 14 V-BELT SET (INCLUDES 3-BELTS)(FAN DRIVE) | 1 | |
| 4N6288 | 15 PULLEY-FAN DRIVE (3-GROOVE) | 1 | |
| 3L1425 | 16 BALL BEARING | 1 | |
| 7N2900 | 17 RETAINER | 1 | |
| 6N4088 | 18 ADAPTER-FAN | 1 | |
| 4B4550 | 19 FITTING-PRESSURE RELIEF (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 7X7731 | 20 PLUG-PIPE (3/4-14-THD) | 1 | |
| 5P7979 | 21 BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 9F4446 | 22 SEAL-O-RING | 1 | |
| 0L2070 | 23 BOLT (3/8-16X2.25-IN) | 6 | |
| 1F7958 | 24 NUT-FULL (1/2-13-THD) | 4 | |
| 2D4867 | 25 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 |
