System And Components
8N-6399 DRIVE GP-FAN0.485-DRIVE RATIO
Group No: 8N-6399
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N6288 | 1 PULLEY-FAN DRIVE (3-GROOVE) | 1 | |
| 7N8827 | 2 HUB | 1 | |
| 8N5305 | 3 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 3L1425 | 4 BALL BEARING | 1 | |
| 9F4446 | 5 SEAL-O-RING | 1 | |
| 7N2900 | 6 RETAINER | 1 | |
| 5P7979 | 7 BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 6N6598 | 8 ADAPTER-FAN | 1 | |
| 1B5174 | 9 PLUG-PIPE | 1 | |
| 0L2070 | 10 BOLT (3/8-16X2.25-IN) | 6 | |
| 8H9789 | 11 BALL BEARING | 1 | |
| 6N6490 | 12 BRACKET AS-FAN | 1 | |
| 1P9946 | SHAFT-FAN | 1 | |
| 4N0684 | DOWEL | 1 | |
| 9L5595 | 13 BOLT (3/8-16X5-IN) | 1 | |
| 1D4717 | 14 NUT (3/8-16-THD) | 1 | |
| 6N2538 | 15 BRACKET-FAN ADJUSTMENT | 1 | |
| 0S1594 | 16 BOLT (3/8-16X1-IN) | 2 | |
| 4B4550 | 17 FITTING-PRESSURE RELIEF (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 6N2547 | 18 ADAPTER-FAN BRACKET | 1 | |
| 1F7960 | 19 WASHER (13.5X32X6-MM THK) | 4 | |
| 9L0553 | 20 STUD-TAPERLOCK (1/2-13X4.25-IN) | 4 | |
| 5S9062 | 21 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 5S2106 | 22 SEAL-LIP TYPE | 1 | |
| 1D4719 | 23 NUT-FULL (1/2-13-THD) | 4 | |
| 2D4867 | 24 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 |
