System And Components
8N-6402 DRIVE GP-FAN0.800-DRIVE RATIO
Group No: 8N-6402
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9L0553 | 1 STUD-TAPERLOCK (1/2-13X4.25-IN) | 4 | |
| 1D4719 | NUT-FULL (1/2-13-THD) | 4 | |
| 1F7960 | WASHER (13.5X32X6-MM THK) | 4 | |
| 6N2547 | 2 ADAPTER-FAN BRACKET | 1 | |
| 5S9062 | 3 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 5S2106 | 4 SEAL-LIP TYPE | 1 | |
| 0L2070 | 5 BOLT (3/8-16X2.25-IN) | 6 | |
| 7N8828 | 6 PULLEY-FAN DRIVE (4-GROOVE) | 1 | |
| 7N8827 | 7 HUB | 1 | |
| 3L1425 | 8 BALL BEARING | 1 | |
| 5S7264 | 9 WASHER-RETAINING (0.219-IN THK) | 1 | |
| 7N2900 | RETAINER | 1 | |
| 6N6598 | 10 ADAPTER-FAN | 1 | |
| 1B5174 | 11 PLUG-PIPE | 1 | |
| 1H5403 | 12 BOLT (5/16-24X2-IN) | 2 | |
| 5P7979 | BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 9F4446 | 13 SEAL-O-RING | 1 | |
| 8N5305 | 14 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 8H9789 | 15 BALL BEARING | 1 | |
| 6N6490 | 16 BRACKET AS-FAN | 1 | |
| 1P9946 | SHAFT-FAN | 1 | |
| 4N0684 | DOWEL | 1 | |
| 2D4867 | 17 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 9L5595 | 18 BOLT (3/8-16X5-IN) | 1 | |
| 1D4717 | NUT (3/8-16-THD) | 1 | |
| 0S1594 | 19 BOLT (3/8-16X1-IN) | 2 | |
| 6N2538 | 20 BRACKET-FAN ADJUSTMENT | 1 | |
| 4B4550 | 21 FITTING-PRESSURE RELIEF (1/8-27 PTF)(FAN DRIVE) | 1 |
