Assembly
100%

7E-9052 GUARD GP-BELTFOR USE WITH WIDE FRONT ENGINE SUPPORT OR 10 INCH RAILS

Group No: 7E-9052
Part NumberPart NameQty
7E97851 GUARD AS1
1F0750NUT-WELD (3/8-16-THD)1
4K9097NUT-WELD (5/16-18-THD)5
7E97872 COVER AS-DAMPER1
4K9097NUT-WELD (5/16-18-THD)3
7E97923 COVER AS1
4K9097NUT-WELD (5/16-18-THD)2
7E97934 COVER AS1
4K9097NUT-WELD (5/16-18-THD)3
7E97955 SHROUD AS (RH)1
7E97966 SHROUD AS (LH)1
7E97897 SPACER AS1
7E97918 PLATE1
7E97909 SUPPORT1
8T904310 BOLT (5/16-18X0.875-IN)8
8T422411 WASHER-HARD (8.8X16X2-MM THK)10
5S737912 BOLT (3/8-16X0.875-IN)7
8T489613 WASHER-HARD (10.2X18.5X2.5-MM THK)12
1S483614 SPACER (0.438X0.75X2.12-IN THK)1
7X029015 BOLT (3/8-16X3.5-IN)1
4P198216 COVER1
5S738317 BOLT (3/8-16X1.75-IN)2
6V880118 NUT (3/8-16-THD)2
5K090619 BOLT (5/16-18X0.625-IN)2
