System And Components
6N-2506 TURBOCHARGER GPS/N 67U11135-11377
Group No: 6N-2506
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9N2031 | 1 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 9N2035 | HOUSING AS-CENTER | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 9N3701 | 2 SHROUD | 1 | |
| 9N2043 | 3 WHEEL & SHAFT AS | 1 | |
| 7N3759 | 4 RING-PISTON | 1 | |
| 9M8915 | 5 RING-RETAINING | 3 | |
| 9N2045 | 6 PLATE AS-BACKING | 1 | |
| 9N2041 | 7 KIT-BEARING | 1 | |
| 6N5004 | 8 BEARING-THRUST | 1 | |
| 9M8911 | 9 COLLAR-THRUST | 1 | |
| 9N2046 | 10 SPACER-THRUST | 1 | |
| 9M8919 | 11 RING-SEAL | 2 | |
| 1S1770 | 12 LOCKNUT-TURBOCHARGER | 1 | |
| 9N2040 | 13 WHEEL-COMPRESSOR | 1 | |
| 0S1616 | 14 BOLT (1/4-20X1-IN) | 4 | |
| 9N2036 | 15 PLATE-LOCK | 4 | |
| 1P1120 | 16 RING-SEAL | 1 | |
| 9N2038 | 17 CLAMP AS-TURBINE | 1 | |
| 6N4585 | 18 HOUSING | 1 | |
| 1S4295 | 20 GASKET (TURBOCHARGER) | 1 | |
| 2N2766 | 21 LOCKNUT (3/8-16-THD) | 4 | |
| 9N2042 | 22 HOUSING-COMPRESSOR | 1 | |
| 9N2039 | 23 CLAMP AS (COMPRESSOR) | 1 |
