System And Components
6N-3298 TURBOCHARGER GPPART OF 6N-3491 TURBOCHARGER GP
Group No: 6N-3298
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9L6239 | 1 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 9L6242 | WHEEL-COMPRESSOR | 1 | |
| 3S4484 | 2 LOCKNUT-TURBOCHARGER (5/16-24-THD) | 1 | |
| 3S5135 | 3 SEAL-O-RING | 1 | |
| 3S4489 | 4 SEAL-O-RING | 1 | |
| 8S5169 | 5 PLATE AS-THRUST | 1 | |
| 9L6243 | 6 HOUSING AS | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 7N3760 | 7 SHROUD | 1 | |
| 9L6244 | 8 WHEEL AS | 1 | |
| 7N3759 | 9 RING-PISTON | 1 | |
| 9N2041 | 10 KIT-BEARING (INCLUDES 2) | 1 | |
| 9M8915 | 11 RING-RETAINING | 3 | |
| 8S8043 | 12 SPACER-THRUST | 1 | |
| 9M8919 | 13 RING-SEAL | 3 | |
| 9M8917 | 14 BEARING | 1 | |
| 8S8042 | 15 COLLAR-THRUST | 1 | |
| 3S4488 | 16 SCREW-MACHINE | 3 | |
| 3S4487 | PLATE-LOCK | 3 | |
| 9L6240 | 19 HOUSING-COMPRESSOR | 1 | |
| 9N6605 | 20 HOUSING | 1 | |
| 3S5126 | 21 BOLT-HIGH TEMPERATURE (3/8-16X0.625-IN) | 6 | |
| 3S5127 | PLATE-CLAMP | 3 | |
| 3S5128 | PLATE-LOCK | 3 | |
| 3S5129 | 22 CLAMP AS (COMPRESSOR) | 1 | |
| 6N7239 | KIT-CARTRIDGE (TURBOCHARGER) | 1 |
