System And Components
6N-6127 TURBOCHARGER GPPART OF 6N-2951 TURBOCHARGER GP
Group No: 6N-6127
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N9905 | 1 HOUSING AS-TURBINE | 1 | |
| 4N0932 | 2 PLUG-CUP (57.53-MM OD) | 1 | |
| 1B5174 | 3 PLUG-PIPE | 4 | |
| 9N2038 | 4 CLAMP AS-TURBINE | 1 | |
| 6N4650 | 5 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 9N2035 | HOUSING AS-CENTER | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 1S1770 | 6 LOCKNUT-TURBOCHARGER | 1 | |
| 9N2040 | 7 WHEEL-COMPRESSOR | 1 | |
| 9N2046 | 8 SPACER-THRUST | 1 | |
| 9M8919 | 9 RING-SEAL | 2 | |
| 9M8911 | 10 COLLAR-THRUST | 1 | |
| 0S1616 | 11 BOLT (1/4-20X1-IN) | 4 | |
| 9N2036 | PLATE-LOCK | 4 | |
| 9N2045 | 12 PLATE AS-BACKING | 1 | |
| 1P1120 | 13 RING-SEAL | 1 | |
| 6N5004 | 14 BEARING-THRUST | 1 | |
| 9M8915 | 15 RING-RETAINING | 3 | |
| 9N2041 | 16 KIT-BEARING | 1 | |
| 9N3701 | 17 SHROUD | 1 | |
| 7N3759 | 18 RING-PISTON | 1 | |
| 6N4606 | 19 WHEEL & SHAFT AS | 1 | |
| 9N2039 | 21 CLAMP AS (COMPRESSOR) | 1 | |
| 9N2042 | 22 HOUSING-COMPRESSOR | 1 |
