System And Components
7N-1241 PUMP GP-FUEL INJECTIONPART OF 7N-1242 PUMP GP-GOV, FUEL INJ & TFR
Group No: 7N-1241
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3L5987 | 1 COVER | 1 | |
| 8S5388 | 2 GASKET | 1 | |
| 2A0762 | 3 BOLT (1/4-20X0.625-IN) | 1 | |
| 9S4191 | 4 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | 5 SEAL-O-RING | 1 | |
| 6N2574 | 6 COVER | 1 | |
| 4N1636 | 7 GASKET | 1 | |
| 8H9204 | 8 WASHER-FELT (19/32X7/8X5/16-IN THK) | 8 | |
| 7E5085 | 9 BUSHING-TERMINAL | 8 | |
| 9S8008 | 10 PLUG (1-1/16-12-THD) | 2 | |
| 3D2824 | 11 SEAL-O-RING | 2 | |
| 7N2694 | 12 BRACKET AS-CONTROL | 1 | |
| 6N6955 | 13 PIN | 1 | |
| 7N2693 | 14 SPRING-TORSION | 1 | |
| 1T0284 | 15 BOLT-SOCKET HEAD (5/16-18X1-IN) | 1 | |
| 4N1572 | 16 LINK-RACK | 1 | |
| 4N0900 | 17 RACK-REGULATOR | 1 | |
| 4N0901 | RACK-REGULATOR | 1 | |
| 1M1077 | 18 SEAL-O-RING | 8 | |
| 7N1185 | 19 PUMP GP-FUEL INJECTION | 8 | |
| 5M2697 | 20 SPACER (1.026X1.285X0.17-IN THK) | 8 | |
| 2M4208 | SPACER (1.027X1.285X0.174-IN THK) | 8 | |
| 2M4209 | SPACER (1.027X1.285X0.178-IN THK) | 8 | |
| 2M4210 | SPACER (1.027X1.285X0.182-IN THK) | 8 | |
| 4M4211 | SPACER (0.186-IN THK) | 8 | |
| 2M4212 | SPACER (1.027X1.285X0.19-IN THK) | 8 | |
| 5M2691 | SPACER (1.027X1.285X0.194-IN THK) | 8 | |
| 5S7189 | SPACER (1.027X1.285X0.198-IN THK) | 8 | |
| 4N0779 | 21 HOUSING GP-FUEL PUMP | 1 | |
| 4W0736 | 22 LIFTER AS | 8 | |
| 4W8140 | 23 CAMSHAFT-FUEL PUMP | 1 | |
| 5P0537 | 24 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 6N2837 | 25 COVER | 1 | |
| 1W1401 | 26 SCREW-RACK STOP | 1 | |
| 6F5926 | 27 NUT | 1 | |
| 6N2833 | LOCK-SETSCREW | 1 | |
| 1L5316 | PIN-SPRING | 1 | |
| 1H3943 | 28 WASHER | 1 | |
| 6N0540 | 29 PLUG | 1 | |
| 3K0360 | 30 SEAL-O-RING | 1 | |
| 7B2742 | 31 BOLT (1/4-20X1.25-IN) | 1 | |
| 7S5757 | 33 RING-RETAINING | 1 | |
| 4N9767 | 34 ADAPTER-GOVERNOR DRIVE | 1 | |
| 8H3127 | 35 BOLT (1/4-20X0.75-IN) | 2 | |
| 4N9766 | 36 PINION-GOVERNOR DRIVE | 1 | |
| 6N2834 | 37 WASHER | 1 | |
| 6N2838 | 38 SHAFT | 1 | |
| 3L6670 | 39 RETAINER-DRIVE | 1 | |
| 6N2839 | 40 SHAFT | 1 | |
| 7J9018 | 41 BOLT-SOCKET HEAD (10-24X0.625-IN) | 2 | |
| 6N2836 | 42 LEVER-RACK STOP | 1 | |
| 0310215 | 43 BOLT-LOCKING (1/4-20X0.625-IN) | 1 | |
| 4N0907 | 44 LEVER-SHUTOFF | 1 | |
| 4N0905 | 45 GEAR-BEVEL (42-TEETH) | 1 | |
| 4N0776 | 46 RETAINER | 1 | |
| 0S1618 | 47 BOLT (5/16-18X1-IN) | 3 | |
| 5M6214 | 48 PLUG (1/8-27 PTF) | 1 | |
| 6N2835 | 49 LEVER-SHUTOFF | 1 | |
| 0S1616 | 50 BOLT (1/4-20X1-IN) | 1 |
